Technical Specification
Voltage
220-240V
Hertz
50 Hz
Cooling Capacity
4.9(2.3~5.6)kW
Cooling EER(W/W)
3.3
Heating Capacity
5.3(2.3~5.7)kW
Heating COP(W/W)
3.4
Moisture Removal(L/h)
1.7
Max. Input Consumption (W)
2250
Max. Current(A)
10.2
Compressor Type
ROTARY
Indoor Air Flow (Hi/Mi/Lo)(m3/h)
800/710/630
Indoor Sound Power Level (Hi/Mi/Lo)(dB(A))
43/38/34
Outdoor Air Flow(m3/h)
2200
Outdoor Sound Power Level(dB(A))
59
Refrigerant Type
R410A/1180g
Refrigerant Piping
Liquid side/ Gas side(mm(inch)
f6.35/f12.7(1/4"/1/2")
Max. Refrigerant pipe Length (m)
20
Max. Difference in Level(m)
8
Operation temperature
Indoor(cooling/ heating)(?)
=17/=30
Outdoor(cooling/heating)(?)
0~50/-15~30
Weight and Dimension
Indoor Unit Weight
11.5 Kg/ 25.35 Lbs.
Indoor Shipping Weight
14.5 Kg/ 31.95 Lbs.
Indoor Unit Dimension
11.5”H x 36.2”W x 8.9”D (292x920x225 mm)
Indoor Shipping Dimension
14.5”H x 40”W x 11.6”D (368x1015x295 mm)
Outdoor Unit Weight
40.5 Kg/ 89.28 Lbs.
Outdoor Shipping Weight
43 Kg/ 94.79 Lbs.
Outdoor Unit Dimension
23.2”H x 29.9”W x 11.2”D (590x760x285 mm)
Outdoor Shipping Dimension
25.7”H x 34.9”W x 15.2”D (655x887x385 mm)
Qty’ per 20’ /40’ /40'HQ
89/182/215
18000 BTU Heat & Cool R410A ENVIRONMENTALLY FRIENDLY REFRIGERANTRoHS Approvals3 Speed SettingAuto Restart FunctionTurbo ModeTemperature compensation Electrostatic Carbon FilterSelf-Diagnosis and auto protectionAuto-air conditioning automatically saves settings and restores them when the Power ResumesTurbo mode for faster coolingTwo-Direction Air VaneValue Safety CoverComfort Sleep Function Low noiseAnti-Rust Condensing Unit Hydrophilic Blue fins Easy Panel Cleaning
