Technical Specification Voltage 220-240V 50HZ 1Ph Cooling capacity 5.70 Power Input 2001 EER 2.85 Energy Class C Heating Capacity 6.02 COP 3.39 Power Input 1776 Energy Class C Max current 15.00 Compressor type Rotary Indoor Unit Air Flow (H/M/L) 720/550/450 Noise level (H/M/L) 46.2/42.4/36.1 Dimensions (H/W/D) (Body) 570x260x570 Dimensions (H/W/D) (panel) 650x50x650 Weight (body) 19 Weight (panel) 2.5 Shipping Weight: Indoor: 21 Kg Shipping Dimension Indoor: 25.8”H x 25.8”W x 11.4”D (655x655x290 mm) Outdoor unit Air flow 2439 Noise Level 58.7 Maximum pipe length 25 Maximum height difference 15 Dimensions (WXHXD) 760x590x285 Weight 39 Shipping Weight: Outdoor: 42 Kg Shipping Dimension Outdoor: 25.8”H x 34.9”W x 15.2”D x (655x887x385 mm) Refrigerant piping (liquid/gas) ¼”/ ½” Refrigerant type R410A Ambient temperature (cooling/heating) 18¸43/ -7¸24 Cooling Capacities are based on 27ºC (DB)/19ºC (WB) indoor air temperature and 35ºC (DB) / 24ºC (WB) outdoor air temperature Heating Capacities are based on 20ºC (DB) / 15ºC (WB) indoor air temperature and 7ºC (DB) / 6ºC (WB) outdoor air temperature. H/M/L: High - Medium - Low speed
Technical Specification
Voltage
220-240V 50HZ 1Ph
Cooling capacity
5.70
Power Input
2001
EER
2.85
Energy Class
C
Heating Capacity
6.02
COP
3.39
1776
Max current
15.00
Compressor type
Rotary
Indoor Unit
Air Flow (H/M/L)
720/550/450
Noise level (H/M/L)
46.2/42.4/36.1
Dimensions (H/W/D) (Body)
570x260x570
Dimensions (H/W/D) (panel)
650x50x650
Weight (body)
19
Weight (panel)
2.5
Shipping Weight:
Indoor: 21 Kg
Shipping Dimension
Indoor: 25.8”H x 25.8”W x 11.4”D (655x655x290 mm)
Outdoor unit
Air flow
2439
Noise Level
58.7
Maximum pipe length
25
Maximum height difference
15
Dimensions (WXHXD)
760x590x285
Weight
39
Outdoor: 42 Kg
Outdoor: 25.8”H x 34.9”W x 15.2”D x (655x887x385 mm)
Refrigerant piping (liquid/gas)
¼”/ ½”
Refrigerant type
R410A
Ambient temperature (cooling/heating)
18¸43/ -7¸24
Cooling Capacities are based on
27ºC (DB)/19ºC (WB) indoor air temperature and 35ºC (DB) / 24ºC (WB) outdoor air temperature
Heating Capacities are based on
20ºC (DB) / 15ºC (WB) indoor air temperature and 7ºC (DB) / 6ºC (WB) outdoor air temperature. H/M/L: High - Medium - Low speed
3 Fan speed (High, Medium, Low)Equal and wide range efficient coolingLow noise operation24 Hours timer setting3D Screw indoor fan technology that reduces air resistance & noise level, results in increased air volume and heat exchange efficiency360°C Air flow panel to ensure uniform airflow distributionFresh air intake provision within the indoor unitProvision of sub-duct connection from indoor unit for adjacent small roomRib design on the decorative panel to prevent from distortionInside (-box design that is accessible form return air grilleIn Built drain pump for condensate lift up to 750mmError code display on LED panel on indoor unitUltra-thin machine for easy installation and maintenanceMinimum height 230 mm
