Technical Specification Size 12000 Btu, 3.3K Performance Energy Class 2013 (Cooling/Heat pump) A/A+ Rated Cooling Capacity (W) 3,374 Rated Heating Capacity (W) 3,004 Dehumidification (liters/hour) 1.5 Rated EER (W/W) 2.6 Rated COP(W) 2.73 Approximately Room Size (m²) 24 Refrigeration R410a Charge (grams) 550 Electrical Volts/Hertz 220-240V 50HZ Amps (Cool) 5.7 Amps (Heat) 5.0 Rated Watts (Cooling) 1290 Rated Watts (Heating) 1070 Maximum Rated Input(W) 1600 Maximum Rated Current(A) 8 Fuse(A) 3.15 Operating Pressure H/L(Mpa) 4.2/1.5 Standby Power (W) 0.5 Power Cord Length From Unit (m) 1.4 Features Controls Electric Control Panel Location TOP Fan Speeds (Cool/Fan/Heat) 3/3/3 Auto Fan Yes Energy Saver Yes Sleep Mode Yes 24 Hour On/Off Timer Yes 24 Hour timer ON and Timer OFF Yes Clean Air Ionizer (Ion Generator) Yes Dry (dehumidification) Yes Full Auto (Unit sets mode) Yes Air Volume (CFM) (High/Med/Low) 386/327/305 Motor RPM (High/Med/Low) 780/680/600 Air Discharge Top of Unit Air Direction Control Swing Noise Level dB(A) in Sound Power (Hi/Mid/Low) 64/61/58 Noise Level dB(A) in Sound Pressure (Hi/Mid/Low) 53/50/45 Filter Type DUST FILTER Filter Access Rear Top Cabinet Color White and Gray Rear Grill Yes Accessories Included Yes Front Material HIPS Textile cover Yes Global Warming Potential, GWP 2100 Certifications LVD Safety Yes EMC Yes RoHS Yes Weight & Dimensions Unit size (W/D/H)(cm) 46.5*39.7*76.4 Shipping size(W/D/H)(cm) 52.5*44.5*87.0 Recommended Stack Height 3 Unit Weight (Kg) 34.0 Shipping Weight (Kg) 37.5
Technical Specification
Size
12000 Btu, 3.3K
Performance
Energy Class 2013 (Cooling/Heat pump)
A/A+
Rated Cooling Capacity (W)
3,374
Rated Heating Capacity (W)
3,004
Dehumidification (liters/hour)
1.5
Rated EER (W/W)
2.6
Rated COP(W)
2.73
Approximately Room Size (m²)
24
Refrigeration
R410a
Charge (grams)
550
Electrical
Volts/Hertz
220-240V 50HZ
Amps (Cool)
5.7
Amps (Heat)
5.0
Rated Watts (Cooling)
1290
Rated Watts (Heating)
1070
Maximum Rated Input(W)
1600
Maximum Rated Current(A)
8
Fuse(A)
3.15
Operating Pressure H/L(Mpa)
4.2/1.5
Standby Power (W)
0.5
Power Cord Length From Unit (m)
1.4
Features
Controls
Electric
Control Panel Location
TOP
Fan Speeds (Cool/Fan/Heat)
3/3/3
Auto Fan
Yes
Energy Saver
Sleep Mode
24 Hour On/Off Timer
24 Hour timer ON and Timer OFF
Clean Air Ionizer (Ion Generator)
Dry (dehumidification)
Full Auto (Unit sets mode)
Air Volume (CFM) (High/Med/Low)
386/327/305
Motor RPM (High/Med/Low)
780/680/600
Air Discharge
Top of Unit
Air Direction Control
Swing
Noise Level dB(A) in Sound Power (Hi/Mid/Low)
64/61/58
Noise Level dB(A) in Sound Pressure (Hi/Mid/Low)
53/50/45
Filter Type
DUST FILTER
Filter Access
Rear Top
Cabinet Color
White and Gray
Rear Grill
Accessories Included
Front Material
HIPS
Textile cover
Global Warming Potential, GWP
2100
Certifications
LVD Safety
EMC
RoHS
Weight & Dimensions
Unit size (W/D/H)(cm)
46.5*39.7*76.4
Shipping size(W/D/H)(cm)
52.5*44.5*87.0
Recommended Stack Height
3
Unit Weight (Kg)
34.0
Shipping Weight (Kg)
37.5
RoHS, LVD, EMC Certificate R410a Refrigeration Remote ControlHigh efficiency3 Adjustable speedsAdjustable LouversFull Auto (Unit sets mode) Oscillating air vanes for dissipation of cold air24 Hr. Timer FeatureClean Air Ionizer (Ion Generator)Dry (dehumidification)24 m² Approximately Room Size Sleep FunctionHigh efficiency air filters to remove odors and particlesAnti-mold coating for hygienic operation
