Technical SpecificationVoltage220-240VFrequency50HZCapacity18000 BTUFan Speed3 (Low, Med, High)Auto speedYesMode4 (Cool, Dry, Fan, Heat)Timer0-24 hoursTemperature settingYesCooling Capacity5300WHeating capacity5000WCooling Power Input1600WHeating Power Input1500WRated Input2000WComp. LRA40APressure (Discharge/Suction)4.3/2.5 MPaMaximum allowable Pressure4.3MPaSound Pressure Lever (Indoor/Outdoor)55/63dB (A)Air Swing functionYesFilter IndicatorYesON/OFF ButtonYesOpen/Close VentYesRefrigerantR410ARefri. Charge1.3 kgMoisture Protection ( Outdoor part)IPX4IsolationIColorWhiteWorking temperature rangeIndoor side cooling32/23 DB/WB(°C)Outdoor side cooling43/- DB/WB(°C)Indoor side heating27/- DB/WB(°C)Outdoor side heating24/18 DB/WB(°C)Operating outdoor temperature range for cooling18°C~43°COperating outdoor temperature range for heating-7°C~43°CWeight and DimensionsUnit Dimension17"H x 26.12"W x 31"DUnit Weight150 Lb. / 68 kg.Shipping Dimension20.25"H x 33.75"W x 29.25"DShipping Weight161 Lb. / 73kg.
Technical Specification
Voltage
220-240V
Frequency
50HZ
Capacity
18000 BTU
Fan Speed
3 (Low, Med, High)
Auto speed
Yes
Mode
4 (Cool, Dry, Fan, Heat)
Timer
0-24 hours
Temperature setting
Cooling Capacity
5300W
Heating capacity
5000W
Cooling Power Input
1600W
Heating Power Input
1500W
Rated Input
2000W
Comp. LRA
40A
Pressure (Discharge/Suction)
4.3/2.5 MPa
Maximum allowable Pressure
4.3MPa
Sound Pressure Lever (Indoor/Outdoor)
55/63dB (A)
Air Swing function
Filter Indicator
ON/OFF Button
Open/Close Vent
Refrigerant
R410A
Refri. Charge
1.3 kg
Moisture Protection ( Outdoor part)
IPX4
Isolation
I
Color
White
Working temperature range
Indoor side cooling
32/23 DB/WB(°C)
Outdoor side cooling
43/- DB/WB(°C)
Indoor side heating
27/- DB/WB(°C)
Outdoor side heating
24/18 DB/WB(°C)
Operating outdoor temperature range for cooling
18°C~43°C
Operating outdoor temperature range for heating
-7°C~43°C
Weight and Dimensions
Unit Dimension
17"H x 26.12"W x 31"D
Unit Weight
150 Lb. / 68 kg.
Shipping Dimension
20.25"H x 33.75"W x 29.25"D
Shipping Weight
161 Lb. / 73kg.
Heat & Cool Remote control 3 Fan Speed (Low, Med, High)Auto speed function 4 Mode (Cool, Dry, Fan, Heat) 0-24 Hours TimerTemperature setting buttonON/OFF ButtonOpen/Close VentSwing button-activate the automatic air swing function Filter Indicator button
