Technical Specification Voltage and Frequency 220-240V 50/60HZ 1Ph Oven Capacity 5.3 Cu. Ft. Lower Storage Drawer Capacity 0.7 Cu. Ft. Broiler Element Power 3400 @ 240V Bake Element Power 2400 @ 240V Amps 40 Oven Type Self Cleaning Knobs 11” Splashguard with 4 Knobs Display Type LED Clock Yes Timer Yes Controls Easy Touch Electronic Control Lock Yes Heating Elements 5 Radiant Heating Elements Left Front: Dual, 12”/9”, 3000 Watt Right Front: 10”, 2500 Watt Left Rear: 6”, 1200 Watt Right Rear: 6”, 1200 Watt Center (Warming Center): 6”, 100 Watt Hot Surface Indicator Light Yes Cooktop Indicator Light Yes Oven On Indicator Light Yes Delay Start Yes Broil Temperature 5-degree increments 300°-525°F Automatic Door Latch Yes Oven Light Yes Oven Racks 2 Oven Racks Positions 5 Color White Finish Weight and Dimension Product Dimension 46.8"H x 29.8"W x 27.7"D Product Shipping Dimension 48.5"H x 31.5"W x 28.5"D Product Weight 168lbs.
Technical Specification
Voltage and Frequency
220-240V 50/60HZ 1Ph
Oven Capacity
5.3 Cu. Ft.
Lower Storage Drawer Capacity
0.7 Cu. Ft.
Broiler Element Power
3400 @ 240V
Bake Element Power
2400 @ 240V
Amps
40
Oven Type
Self Cleaning
Knobs
11” Splashguard with 4 Knobs
Display Type
LED
Clock
Yes
Timer
Controls
Easy Touch Electronic
Control Lock
Heating Elements
5 Radiant Heating Elements
Left Front: Dual, 12”/9”, 3000 Watt
Right Front: 10”, 2500 Watt
Left Rear: 6”, 1200 Watt
Right Rear: 6”, 1200 Watt
Center (Warming Center): 6”, 100 Watt
Hot Surface Indicator Light
Cooktop Indicator Light
Oven On Indicator Light
Delay Start
Broil Temperature
5-degree increments 300°-525°F
Automatic Door Latch
Oven Light
Oven Racks
2
Oven Racks Positions
5
Color
White Finish
Weight and Dimension
Product Dimension
46.8"H x 29.8"W x 27.7"D
Product Shipping Dimension
48.5"H x 31.5"W x 28.5"D
Product Weight
168lbs.
Broiler Element Power 3400 @ 240VBake Element Power 2400 @ 240VExtra Large Clear Oven Window with Towel Bar11” Splashguard with 4 Knobs, LED Display with Clock & Timer, Easy-Touch Electronic Controls and Control Lock5 Radiant Heating Elements:Left Front: Dual, 12”/9”, 3000 WattRight Front: 10”, 2500 WattLeft Rear: 6”, 1200 WattRight Rear: 6”, 1200 WattCenter (Warming Center): 6”, 100 WattHot Surface Indicator LightCooktop On Indicator LightOven On Indicator LightRecessed Broiler (top of oven)Delay Start and Keep Warm SettingsAccuBake™ Temperature Management System offers uniform baking results every timeCustom Broil (5-degree increments 300°-525°F)Broiler Element Power 3400 @ 240VBake Element Power 2400 @ 240VAutomatic Door Latch2 Oven Racks5 Oven Rack PositionsWhite Finish color
