Technical Specification VOLTAGE 120/240V 60HZ CONTROL OPTION Manual Homestyle COLOR White CAPACITY - lb (kg) 18 (8.2) (ea) CYLINDER VOLUME - cu. ft. (liters) 7.0 (198) (ea) MOTOR (CAPACITOR START AND THERMAL PROTECTED) .33 HP TYPE OF GAS (GAS MODELS ONLY) Factory equipped natural/mixed gas AIR OUTLET DIAMETER - in (mm) 4 (102) EXHAUST AIRFLOW - cfm (liters/sec) 220 (105) AVAILABLE CYCLES Regular, Permanent Press, Delicate, Time Dry, Quick Dry, Fluff Up ELECTRICAL 120/240/60/1-30 amp HEATING ELEMENT 5350W, 240V NET WEIGHT - lb (kg) 262 (119) SHIPPING WEIGHT 272 (123.4) WEIGHT AND DIMENSIONS UNIT DIMENSIONS in (mm) 26.875 (683) Width 28 (711) Depth 75.38 (1915) Height SHIPPING DIMENSIONS APPROX. - in (mm) 30 (762) Depth 80 (2032) Height 33 (838) Width Approval cULus
Technical Specification
VOLTAGE
120/240V 60HZ
CONTROL OPTION
Manual Homestyle
COLOR
White
CAPACITY - lb (kg)
18 (8.2) (ea)
CYLINDER VOLUME - cu. ft. (liters)
7.0 (198) (ea)
MOTOR (CAPACITOR START AND THERMAL PROTECTED)
.33 HP
TYPE OF GAS (GAS MODELS ONLY)
Factory equipped natural/mixed gas
AIR OUTLET DIAMETER - in (mm)
4 (102)
EXHAUST AIRFLOW - cfm (liters/sec)
220 (105)
AVAILABLE CYCLES
Regular, Permanent Press, Delicate, Time Dry, Quick Dry, Fluff Up
ELECTRICAL
120/240/60/1-30 amp
HEATING ELEMENT
5350W, 240V
NET WEIGHT - lb (kg)
262 (119)
SHIPPING WEIGHT
272 (123.4)
WEIGHT AND DIMENSIONS
UNIT DIMENSIONS in (mm)
26.875 (683) Width
28 (711) Depth
75.38 (1915) Height
SHIPPING DIMENSIONS APPROX. - in (mm)
30 (762) Depth
80 (2032) Height
33 (838) Width
Approval
cULus
Commercial gradeNo coin boxSpeed Queen brand same washer manufacturer7 cycleVent kits connector includedFront mounted lint screenWhite color4 wire cord included3 Years warranty on partsManual HomestyleSolid door Built for Reliable PerformanceIndustry’s largest door opening 2.06 sq. ft. (1914 cm²)Quiet, efficient blower systemDoor is reversible for installation flexibilityHigh efficiency exhaust blower with superior airflow 220 cfm (105 liters/sec)100% serviceable from the frontSpace-saving narrow cabinet 26.875" (683 mm)Upfront lint filter easy to clean and securedDurable galvanized steel cylinderManual Homestyle control provides easy to start activation indicated by "In Use" light.
