Technical SpecificationVoltage220-240VHertz50HZCooling Capacity 6.5(3.5~7.3)kWCooling EER(W/W)3.24Heating Capacity7.3(3.2~7.9)kWHeating COP(W/W)3.32Moisture Removal(L/h)2.40 Max. Input Consumption(W)2,750Max. Current(A)12Compressor TypeROTARYIndoor Air Flow (Hi/Mi/Lo)(m3/h)1100/1050/930Indoor Sound Power Level (Hi/Mi/Lo)(dB(A))49/43/41Outdoor Air Flow(m3/h)3500Outdoor Sound Power Level(dB(A))57Refrigerant TypeR410A/1900gRefrigerant PipingLiquid side/ Gas side(mm(inch)f9.52/f15.9(3/8"/5/8")Max. Refrigerant pipe Length (m)25Max. Difference in Level(m)10Operation temperatureIndoor(cooling/ heating)(?)=17/=30Outdoor(cooling/heating)(?)0~50/-15~30Weight and DimensionIndoor Unit Weight14.5 KgIndoor Shipping Weight 20.5 Kg Indoor Shipping Dimension12.59”H x 45.86”W x 17.51”D(320x1165x445 mm)Outdoor Unit Weight63.5 KgOutdoor Shipping Weight67.5 Kg Outdoor Unit Dimension33.85”H x 35.43”W x 12.4”D (860x900x315 mm)Outdoor Shipping Dimension 36”H x 41”W x 16.33”D(915x1043x415 mm)Qty’ per 20’ /40’ /40'HQ51/109/118
Technical Specification
Voltage
220-240V
Hertz
50HZ
Cooling Capacity
6.5(3.5~7.3)kW
Cooling EER(W/W)
3.24
Heating Capacity
7.3(3.2~7.9)kW
Heating COP(W/W)
3.32
Moisture Removal(L/h)
2.40
Max. Input Consumption(W)
2,750
Max. Current(A)
12
Compressor Type
ROTARY
Indoor Air Flow (Hi/Mi/Lo)(m3/h)
1100/1050/930
Indoor Sound Power Level (Hi/Mi/Lo)(dB(A))
49/43/41
Outdoor Air Flow(m3/h)
3500
Outdoor Sound Power Level(dB(A))
57
Refrigerant Type
R410A/1900g
Refrigerant Piping
Liquid side/ Gas side(mm(inch)
f9.52/f15.9(3/8"/5/8")
Max. Refrigerant pipe Length (m)
25
Max. Difference in Level(m)
10
Operation temperature
Indoor(cooling/ heating)(?)
=17/=30
Outdoor(cooling/heating)(?)
0~50/-15~30
Weight and Dimension
Indoor Unit Weight
14.5 Kg
Indoor Shipping Weight
20.5 Kg
Indoor Shipping Dimension
12.59”H x 45.86”W x 17.51”D
(320x1165x445 mm)
Outdoor Unit Weight
63.5 Kg
Outdoor Shipping Weight
67.5 Kg
Outdoor Unit Dimension
33.85”H x 35.43”W x 12.4”D
(860x900x315 mm)
Outdoor Shipping Dimension
36”H x 41”W x 16.33”D
(915x1043x415 mm)
Qty’ per 20’ /40’ /40'HQ
51/109/118
R410A ENVIRONMENTALLY FRIENDLY REFRIGERANTRoHS Approvals3 Speed SettingAuto Restart FunctionTurbo ModeTemperature compensation Electrostatic Carbon FilterSelf-Diagnosis and auto protectionAuto-air conditioning automatically saves settings and restores them when the Power ResumesTurbo mode for faster coolingTwo-Direction Air Vane Value Safety CoverComfort Sleep Function Low noiseAnti-Rust Condensing Unit Hydrophilic Blue fins Easy Panel Cleaning
