Technical SpecificationsVoltage220-240VFrequency50HZCapacity12000 BTUFan Speed3 (Low, Med, High)Auto speedYesMode4 (Cool, Dry, Fan, Heat)Timer0-24 hoursTemperature settingYesCooling Capacity3900WHeating capacity3600WCooling Power Input1180WHeating Power Input1090WRated Input1600WComp. LRA26APressure (Discharge/Suction)4.3/2.5 MPaMaximum allowable Pressure4.3MPaSound Pressure Lever (Indoor/Outdoor)53/58dB (A)Air Swing functionYesFilter IndicatorYesON/OFF ButtonYesOpen/Close VentYesRefrigerantR410ARefri. Charge1.10 kgMoisture Protection ( Outdoor part)IP24IsolationIColorWhiteWorking temperature rangeIndoor side cooling32/23 DB/WB(°C)Outdoor side cooling43/- DB/WB(°C)Indoor side heating27/- DB/WB(°C)Outdoor side heating24/18 DB/WB(°C)Operating outdoor temperature range for cooling18°C~43°COperating outdoor temperature range for heating-7°C~43°CWeight and DimensionUnit Dimension:17"H x 26"W x 28"DUnit Weight:126 Lb. / 57 kg.Shipping Dimension:20.5"H x 31"W x 29"DShipping Weight:137 Lb. / 62 kg.
Technical Specifications
Voltage
220-240V
Frequency
50HZ
Capacity
12000 BTU
Fan Speed
3 (Low, Med, High)
Auto speed
Yes
Mode
4 (Cool, Dry, Fan, Heat)
Timer
0-24 hours
Temperature setting
Cooling Capacity
3900W
Heating capacity
3600W
Cooling Power Input
1180W
Heating Power Input
1090W
Rated Input
1600W
Comp. LRA
26A
Pressure (Discharge/Suction)
4.3/2.5 MPa
Maximum allowable Pressure
4.3MPa
Sound Pressure Lever (Indoor/Outdoor)
53/58dB (A)
Air Swing function
Filter Indicator
ON/OFF Button
Open/Close Vent
Refrigerant
R410A
Refri. Charge
1.10 kg
Moisture Protection ( Outdoor part)
IP24
Isolation
I
Color
White
Working temperature range
Indoor side cooling
32/23 DB/WB(°C)
Outdoor side cooling
43/- DB/WB(°C)
Indoor side heating
27/- DB/WB(°C)
Outdoor side heating
24/18 DB/WB(°C)
Operating outdoor temperature range for cooling
18°C~43°C
Operating outdoor temperature range for heating
-7°C~43°C
Weight and Dimension
Unit Dimension:
17"H x 26"W x 28"D
Unit Weight:
126 Lb. / 57 kg.
Shipping Dimension:
20.5"H x 31"W x 29"D
Shipping Weight:
137 Lb. / 62 kg.
Heat & Cool Remote control 3 Fan Speed (Low, Med, High)Auto speed function 4 Mode (Cool, Dry, Fan, Heat) 0-24 Hours TimerTemperature setting buttonON/OFF ButtonOpen/Close VentSwing button-activate the automatic air swing function Filter Indicator button
