Technical SpecificationsVoltage220-240VFrequency50HZCapacity21000 BTUFan Speed3 (Low, Med, High)Auto speedYesMode4 (Cool, Dry, Fan, Heat)Timer0-24 hoursTemperature settingYesCooling Capacity6000WHeating capacity5500WCooling Power Input1830WHeating Power Input1760WRated Input2400WPressure (Discharge/Suction)4.3/2.5 MPaMaximum allowable Pressure4.3 MPaSound Pressure Lever (Indoor/Outdoor)56/64dB(A)Air Swing functionYesFilter IndicatorYesON/OFF ButtonYesOpen/Close VentYesRefrigerantR410ARefrigerant charge1.34 kgMoisture Protection ( Outdoor part)IPX4IsolationIColorWhiteWorking temperature rangeIndoor side cooling32/23 DB/WB(°C)Outdoor side cooling43/- DB/WB(°C)Indoor side heating27/- DB/WB(°C)Outdoor side heating24/18 DB/WB(°C)Operating outdoor temperature range for cooling18°C~43°COperating outdoor temperature range for heating-7°C~43°CWeight and DimensionsUnit Dimension17"H x 26.12"W x 31"DUnit Weight155 Lb./ 70kg .Shipping Dimension20.25"H x 33.75"W x 39.25"DShipping Weight165 Lb./ 75kg
Technical Specifications
Voltage
220-240V
Frequency
50HZ
Capacity
21000 BTU
Fan Speed
3 (Low, Med, High)
Auto speed
Yes
Mode
4 (Cool, Dry, Fan, Heat)
Timer
0-24 hours
Temperature setting
Cooling Capacity
6000W
Heating capacity
5500W
Cooling Power Input
1830W
Heating Power Input
1760W
Rated Input
2400W
Pressure (Discharge/Suction)
4.3/2.5 MPa
Maximum allowable Pressure
4.3 MPa
Sound Pressure Lever (Indoor/Outdoor)
56/64dB(A)
Air Swing function
Filter Indicator
ON/OFF Button
Open/Close Vent
Refrigerant
R410A
Refrigerant charge
1.34 kg
Moisture Protection ( Outdoor part)
IPX4
Isolation
I
Color
White
Working temperature range
Indoor side cooling
32/23 DB/WB(°C)
Outdoor side cooling
43/- DB/WB(°C)
Indoor side heating
27/- DB/WB(°C)
Outdoor side heating
24/18 DB/WB(°C)
Operating outdoor temperature range for cooling
18°C~43°C
Operating outdoor temperature range for heating
-7°C~43°C
Weight and Dimensions
Unit Dimension
17"H x 26.12"W x 31"D
Unit Weight
155 Lb./ 70kg .
Shipping Dimension
20.25"H x 33.75"W x 39.25"D
Shipping Weight
165 Lb./ 75kg
Heat & Cool Remote control 3 Fan Speed (Low, Med, High)Auto speed function 4 Mode (Cool, Dry, Fan, Heat) 0-24 Hours TimerTemperature setting buttonON/OFF ButtonOpen/Close VentSwing button-activate the automatic air swing function Filter Indicator button
