Model FARC24GNBWM Voltage, Hertz 220-240V 50HZ Type Cooling Only BTU/Hr (cool) 24000 SYSTEM FEATURES Amps (cool) 9.57 Watts (cool) 2158 Energy Class (EER / COP) A Refrigerant R410A Compressor Type Rotary Dehumidification (L/pints per hr) 2.4 / 5.1 Connection Pipe Liquid (mm/in) 6.35 / .25 Connection Pipe Gas (mm/in) 16.0 / .63 Approvals CE, RoHS Color White EVAPORATOR DIMENSIONS & WEIGHT Height x Width x Depth (mm) 326 x 1178 x 252 Height x Width x Depth (in) 12.8 x 46.4 x 9.9 Net Weight (kg/lb) 18.0 / 39.6 CONDENSER DIMENSIONS & WEIGHT Height x Width x Depth (mm) 700 x 1018 x 412 Height x Width x Depth (in) 27.6 x 40.1 x 16.2 Net Weight (kg/lb) 56.0 / 123.2 Shipping Weight and Dimension Shipping Dimension Indoor: 14.5"H x 49.5"W x 16.5"D/ outdoor: 30.5"H x 44"W x 18"D Shipping Weight Indoor: 53 Lb./ outdoor: 135.5 Lb. CONTAINER LOADING 20' / 40' / 40'HC without tubing kits 45 / 98 / 113
Model
FARC24GNBWM
Voltage, Hertz
220-240V 50HZ
Type
Cooling Only
BTU/Hr (cool)
24000
SYSTEM FEATURES
Amps (cool)
9.57
Watts (cool)
2158
Energy Class (EER / COP)
A
Refrigerant
R410A
Compressor Type
Rotary
Dehumidification (L/pints per hr)
2.4 / 5.1
Connection Pipe Liquid (mm/in)
6.35 / .25
Connection Pipe Gas (mm/in)
16.0 / .63
Approvals
CE, RoHS
Color
White
EVAPORATOR DIMENSIONS & WEIGHT
Height x Width x Depth (mm)
326 x 1178 x 252
Height x Width x Depth (in)
12.8 x 46.4 x 9.9
Net Weight (kg/lb)
18.0 / 39.6
CONDENSER DIMENSIONS & WEIGHT
700 x 1018 x 412
27.6 x 40.1 x 16.2
56.0 / 123.2
Shipping Weight and Dimension
Shipping Dimension
Indoor: 14.5"H x 49.5"W x 16.5"D/ outdoor: 30.5"H x 44"W x 18"D
Shipping Weight
Indoor: 53 Lb./ outdoor: 135.5 Lb.
CONTAINER LOADING
20' / 40' / 40'HC without tubing kits
45 / 98 / 113
Cooling OnlyRemote Control with Time-of-Day Clock24000 BTU Cool Split Air ConditionerAutomatic 24-Hour On/Off TimerElectronic Display on Evaporator4 Fan Settings (High, Medium, Low and Auto)Sleep Economy Mode, Automatic Restart2 Nylon FiltersSelf-Diagnostic SystemWeather Protection SystemAutomatic Swing Louver ControlMy Temp Comfort SensorBio/HEPA FilterActive Carbon FilterDehumidification FunctionGalvanized Steel Condenser CabinetBlue Fin Technology (Evaporator)Healthy Air Evaporator Cleaning SystemHigh Efficiency Heat Exchanger
