MODEL FARP09GFBWM Voltage 220-240V 50HZ Type Heat Pump BTU/Hr (cool/heat) 9000 / 9400 SYSTEM FEATURES Amps (cool/heat) 3.65 / 3.38 Watts (cool/heat) 822 / 762 Energy Class (EER / COP) A /A Refrigerant R410A Compressor Type Rotary Dehumidification (L/pints per hr) 0.8 / 1.7 Connection Pipe Liquid (mm/in) 6.35 / .25 Connection Pipe Gas (mm/in) 9.52 / .38 Approvals CE, RoHS Color White EVAPORATOR DIMENSIONS & WEIGHT Height x Width x Depth (mm) 265 x 794 x 184 Height x Width x Depth (in) 10.4 x 31.3 x 7.2 Net Weight (kg/lb) 9.0 / 19.8 CONDENSER DIMENSIONS & WEIGHT Height x Width x Depth (mm) 540 x 848 x 320 Height x Width x Depth (in) 21.3 x 33.4 x 12.6 Net Weight (kg/lb) 28.5 / 62.7 Shipping Weight and Dimension Shipping Dimension Indoor: 14.6"H x 34.2"W x 10.2"D/ outdoor: 24"H x 35"W x 14"D Shipping Weight Indoor: 26.5 Lb./ outdoor: 69.5 Lb. CONTAINER LOADING 20' / 40' / 40'HC without tubing kits 101 / 212 / 252
MODEL
FARP09GFBWM
Voltage
220-240V 50HZ
Type
Heat Pump
BTU/Hr (cool/heat)
9000 / 9400
SYSTEM FEATURES
Amps (cool/heat)
3.65 / 3.38
Watts (cool/heat)
822 / 762
Energy Class (EER / COP)
A /A
Refrigerant
R410A
Compressor Type
Rotary
Dehumidification (L/pints per hr)
0.8 / 1.7
Connection Pipe Liquid (mm/in)
6.35 / .25
Connection Pipe Gas (mm/in)
9.52 / .38
Approvals
CE, RoHS
Color
White
EVAPORATOR DIMENSIONS & WEIGHT
Height x Width x Depth (mm)
265 x 794 x 184
Height x Width x Depth (in)
10.4 x 31.3 x 7.2
Net Weight (kg/lb)
9.0 / 19.8
CONDENSER DIMENSIONS & WEIGHT
540 x 848 x 320
21.3 x 33.4 x 12.6
28.5 / 62.7
Shipping Weight and Dimension
Shipping Dimension
Indoor: 14.6"H x 34.2"W x 10.2"D/ outdoor: 24"H x 35"W x 14"D
Shipping Weight
Indoor: 26.5 Lb./ outdoor: 69.5 Lb.
CONTAINER LOADING
20' / 40' / 40'HC without tubing kits
101 / 212 / 252
Heat (Heat Pump) /CoolRemote Control with Time-of-Day Clock9000 / 9400 Heat Pump Split Air ConditionerDeluxe Comfort FunctionAutomatic 24-Hour On/Off TimerElectronic Display on Evaporator4 Fan Settings (High, Medium, Low and Auto)Sleep Economy Mode, Automatic Restart2 Nylon FiltersSelf-Diagnostic SystemWeather Protection SystemAutomatic Swing Louver ControlMy Temp Comfort Sensor * Bio/HEPA FilterActive Carbon Filter * Dehumidification FunctionGalvanized Steel Condenser CabinetBlue Fin Technology (Evaporator and Condenser)Healthy Air Evaporator Cleaning SystemHigh Efficiency Heat Exchanger
