MODEL FARP18GNBWM Voltage 220-240V 50HZ Type Heat Pump BTU/Hr (cool/heat) 18000 / 19700 SYSTEM FEATURES Amps (cool/heat) 7.00 / 7.20 Watts (cool/heat) 1580 / 1605 Energy Class (EER / COP) A /A Refrigerant R410A Compressor Type Rotary Dehumidification (L/pints per hr) 1.8 / 3.8 Connection Pipe Liquid (mm/in) 6.35 / .25 Connection Pipe Gas (mm/in) 12.7 / .50 Approvals CE, RoHS Color White EVAPORATOR DIMENSIONS & WEIGHT Height x Width x Depth (mm) 299 x 945 x 209 Height x Width x Depth (in) 11.8 x 37.2 x 8.2 Net Weight (kg/lb) 12.0 / 26.4 CONDENSER DIMENSIONS & WEIGHT Height x Width x Depth (mm) 680 x 913 x 378 Height x Width x Depth (in) 26.8 x 35.9 x 14.9 Net Weight (kg/lb) 48.0 / 105.6 Shipping Weight and Dimension Shipping Dimension Indoor: 11.5"H x 40"W x 15.5"D/ outdoor: 29.5"H x 39.5"W x 17"D Shipping Weight Indoor: 35.5 Lb./ outdoor: 115 Lb. CONTAINER LOADING 20' / 40' / 40'HC without tubing kits 64 / 135 / 154
MODEL
FARP18GNBWM
Voltage
220-240V 50HZ
Type
Heat Pump
BTU/Hr (cool/heat)
18000 / 19700
SYSTEM FEATURES
Amps (cool/heat)
7.00 / 7.20
Watts (cool/heat)
1580 / 1605
Energy Class (EER / COP)
A /A
Refrigerant
R410A
Compressor Type
Rotary
Dehumidification (L/pints per hr)
1.8 / 3.8
Connection Pipe Liquid (mm/in)
6.35 / .25
Connection Pipe Gas (mm/in)
12.7 / .50
Approvals
CE, RoHS
Color
White
EVAPORATOR DIMENSIONS & WEIGHT
Height x Width x Depth (mm)
299 x 945 x 209
Height x Width x Depth (in)
11.8 x 37.2 x 8.2
Net Weight (kg/lb)
12.0 / 26.4
CONDENSER DIMENSIONS & WEIGHT
680 x 913 x 378
26.8 x 35.9 x 14.9
48.0 / 105.6
Shipping Weight and Dimension
Shipping Dimension
Indoor: 11.5"H x 40"W x 15.5"D/ outdoor: 29.5"H x 39.5"W x 17"D
Shipping Weight
Indoor: 35.5 Lb./ outdoor: 115 Lb.
CONTAINER LOADING
20' / 40' / 40'HC without tubing kits
64 / 135 / 154
Heat (Heat Pump) /CoolRemote Control with Time-of-Day Clock18000 / 19700Heat Pump Split Air ConditionerDeluxe Comfort FunctionAutomatic 24-Hour On/Off TimerElectronic Display on Evaporator4 Fan Settings (High, Medium, Low and Auto)Sleep Economy Mode, Automatic Restart2 Nylon FiltersSelf-Diagnostic SystemWeather Protection SystemAutomatic Swing Louver ControlMy Temp Comfort SensorBio/HEPA FilterActive Carbon FilterDehumidification FunctionGalvanized Steel Condenser CabinetBlue Fin Technology (Evaporator and Condenser)Healthy Air Evaporator Cleaning SystemHigh Efficiency Heat Exchanger
