Technical Specification Function Cooling / Heating Voltage 220-240V Hertz 50HZ Capacity 21000 BTU Fan Speed 4 (Low, Med, High and Auto) Auto speed Yes Mode 4 (Cool, Dry, Fan, Heat and Auto) Timer 0-24 hours Temperature setting Yes Total Capacity (W/Btu/h) Cooling 6000 Watts Heating 5500 Watts Power Input Cooling Power Input 1810 Watts Heating Power Input 1690 Watts Rated Input Cooling 2300 Watts Heating 2500 Watts Hi. Side Pressure 4.3 MPa Low Side Pressure 2.5 MPa Sound Pressure Level(Indoor/Outdoor) 56/64dB(A) Air Swing function Yes Filter Indicator Yes ON/OFF Button Yes Open/Close Vent Yes Refrigerant R32 Refri. Charge 1.05kg Moisture Protection ( Outdoor part) IP24 Working temperature range Indoor side cooling 32/23 DB/WB(°C) Outdoor side cooling 43/- DB/WB(°C) Indoor side heating 27/- DB/WB(°C) Outdoor side heating 24/18 DB/WB(°C) Operating outdoor temperature range for cooling 18°C~43°C Operating outdoor temperature range for heating -7°C~43°C Weight and Dimension Unit Dimension 17"H x 26"W x 30.4"D Unit Weight 68kg Shipping Dimension 20"H x 29"W x 34"D Shipping Weight 73kg
Technical Specification
Function
Cooling / Heating
Voltage
220-240V
Hertz
50HZ
Capacity
21000 BTU
Fan Speed
4 (Low, Med, High and Auto)
Auto speed
Yes
Mode
4 (Cool, Dry, Fan, Heat and Auto)
Timer
0-24 hours
Temperature setting
Total Capacity (W/Btu/h)
Cooling
6000 Watts
Heating
5500 Watts
Power Input
Cooling Power Input
1810 Watts
Heating Power Input
1690 Watts
Rated Input
2300 Watts
2500 Watts
Hi. Side Pressure
4.3 MPa
Low Side Pressure
2.5 MPa
Sound Pressure Level(Indoor/Outdoor)
56/64dB(A)
Air Swing function
Filter Indicator
ON/OFF Button
Open/Close Vent
Refrigerant
R32
Refri. Charge
1.05kg
Moisture Protection ( Outdoor part)
IP24
Working temperature range
Indoor side cooling
32/23 DB/WB(°C)
Outdoor side cooling
43/- DB/WB(°C)
Indoor side heating
27/- DB/WB(°C)
Outdoor side heating
24/18 DB/WB(°C)
Operating outdoor temperature range for cooling
18°C~43°C
Operating outdoor temperature range for heating
-7°C~43°C
Weight and Dimension
Unit Dimension
17"H x 26"W x 30.4"D
Unit Weight
68kg
Shipping Dimension
20"H x 29"W x 34"D
Shipping Weight
73kg
T1 Climate TypeHeat & Cool Remote Control 4 Fan Speed (Low, Med, High and Auto)Swing button-activate the automatic air swing function 4 Mode (Auto, Cool, Dry, Fan, Heat) Sleep function0-24 Hours TimerON/OFF ButtonTemperature setting buttonOpen/Close VentFilter Indicator buttonChild Lock FunctionVDE CertificateISO 9001 Certified
