Technical Specification Voltage and Frequency 220Volt, 50Hz, 18V Rated input power 1,300 W No-load speed 11,500 rpm Disc diameter 125 mm Power output 700 W Grinding spindle thread M14 Rubber backing pad, diameter 125 mm Wire cup brush, diameter 75 mm Total vibration values (Surface grinding (roughing)) Vibration emission value ah 6 m/s² Uncertainty K 1.5 m/s² Total vibration values (Sanding with sanding sheet) Vibration emission value ah 2 m/s² Uncertainty K 1.5 m/s² Noise/vibration information Sound pressure level 102 dB(A) Sound power level 91 dB(A) Uncertainty K 3 dB Surface grinding (roughing) Vibration emission value ah 6 m/s² Uncertainty K 1.5 m/s² Sanding with sanding sheet Vibration emission value ah 2 m/s² Uncertainty K 1.5 m/s Accessories Backing flange (spare part number 2 605 703 014) Locking nut 1 603 340 040 Protective guard 1 605 510 365 Two-hole spanner 1 607 950 043 Vibration Control auxiliary handle 2 602 025 171 Weight and Dimension Unit Dimensions 11.69" W x 4.05" L Unit Weight 5.07 lbs.
Technical Specification
Voltage and Frequency
220Volt, 50Hz, 18V
Rated input power
1,300 W
No-load speed
11,500 rpm
Disc diameter
125 mm
Power output
700 W
Grinding spindle thread
M14
Rubber backing pad, diameter
Wire cup brush, diameter
75 mm
Total vibration values (Surface grinding (roughing))
Vibration emission value ah
6 m/s²
Uncertainty K
1.5 m/s²
Total vibration values (Sanding with sanding sheet)
2 m/s²
Noise/vibration information
Sound pressure level
102 dB(A)
Sound power level
91 dB(A)
3 dB
Surface grinding (roughing)
Sanding with sanding sheet
1.5 m/s
Accessories
Backing flange (spare part number 2 605 703 014)
Locking nut 1 603 340 040
Protective guard 1 605 510 365
Two-hole spanner 1 607 950 043
Vibration Control auxiliary handle 2 602 025 171
Weight and Dimension
Unit Dimensions
11.69" W x 4.05" L
Unit Weight
5.07 lbs.
Overload ProtectionFast work rate due to powerful 1300-watt motor with Constant ElectronicLong lifetime due to motors with direct motor cooling, overload protection and long carbon brush lifetimeLeading user protection due to KickBack Control, restart protection, anti-rotation protective guard and vibration reduction
