Technical Specifications
HDMI input
HDMI 1.3 compliable, support HDCP 1.2
support 1080p 60Hz 12BIT deed color
Input resolutions :
480i@60Hz?480p@60Hz?576i@50Hz?
576p@50Hz?720p@50/60Hz?
1080i@50/60Hz?1080p@50/60Hz;
HDMI graphics resolutions :
6040x480@60Hz?800x600@60Hz?
1024x768@60Hz?1280x600@60Hz?
1280x720@60Hz?1280x768@60Hz?
1280x800@60Hz?1280x960@60Hz?
1280x1024@60Hz?1360x768@60Hz?
1366x768@60Hz?1400x1050@60Hz?
1440x900@60Hz?1600x900@60Hz?
1680x1050@60Hz, 1920x1080@60Hz?
CVBS input
Support NTSC/PA and detect automatically;
1.0Vp-p 75O
S-Video input
Y:1.0Vp-p 75O; C:0.6Vp-p 75O
TV input
PAL/NTSC/SECAM
DDC signal
5Vp-p (TTL)
TMDS signal
0.5-1.0Vp-p
HDMI output
720p@50Hz, 1080p@50Hz, 720p@60Hz, 1080p@60Hz
Coaxial output
PCM /auto/off
Power Consumption
<6W
Product Size
177x78x23.5mm
Supports PAL/NTSC HDMI Input FormatVideo Technology - Provides Precise Vivid Image, even in Fast Action SceneHDMI input, CVBS input, S-Video input, TV inputDDC Signal, TMDS signalHDMI output, Coaxial output
