Technical Specification
Voltage
220-240V 50/60HZ
Body
Desk-top
Copy board
Fixed
Lens
Zoom lens
Photosensitive medium
OPC (f30)
System
Reproduction
Indirect electrostatic
Charging
Corona
Exposure
Slit (moving scanner)
Copy density adjustment
Automatic (AE) or manual
Development
Dry (toner projection)
Pick-up
Auto 2 cassettes
Pedestal (accessory)
Manual Multi feeder
Transfer
Separation
Curvature + static eliminator
Cleaning
Blade
Fixing
main 750 W + sub 640 W for 220/240V model
Performance
Type of original
Sheet, book, 3-D object (2 kg / 4.4lb max.)
Maximum size of original
A3 (297 x 420 mm)/LDG (11” x 17”*)
Reproduction ratio
Direct, 4R4E or 4R3E (Table 1-201), zoom 48~205%(Display range: 49 to 204%)
Wait time
35 sec or less (at 20°C / 68F room temperature)
First copy
5.75 sec or less (A4, Direct, non-AE, pick-up from cassette 1)
Continuous copying
100 copies max.
Copying speed
See Tables 1-202 and 1-203.
Copy size
Cassette: A3 (11” x 17”*) to A5 (STMT*)
Manual: A3 (11” x 17”*) to A6 (Postcard)
Cassette
Plain paper (64 to 80 g/m) tracing paper (SM1),
colored paper* recycled paper (64 to 80 g/m)
Manual
Plain paper (64 to 80 g/m,128 g/m, colored Paper
Two-sided copying
Auto: Plain paper (64 to 80 g/m2), colored paper*2, recycled paper(64 to 80 g/m2)
Manual: Plain paper (64 to 80 g/m2; 128 g/m2*3), colored paper*2,recycled paper (64 to 80 g/m2)
Pick-up capacity
Cassette: 500 sheets (55mm / 2.2”,80g/m2plain paper), front loading (noclaw)
50 sheets (5.5mm / 0.22”,80g/m2 plain paper)
Copy tray
100 sheets (A3 / 11”×17”, plain paper)
Non-image width
2.0 ± 1.0 mm / 0.08” ± 0.04” (leading edge),
2.5 ± 1.5 mm / 0.1” ± 0.06” (left/right, trailing edge)
Auto clear
Provided (2 min standard, may be varied between 0 and 9 min in 1-min increments)
Auto power-off
Provided (60 min standard, may be varied between 10 and 120 min in 10-min increments; may be disabled in service mode)
Accessories
ADF-E1
RDF-F1
Paper Deck Pedestal-M1
MS-B1
Sorter-E1
Stapler Sorter-D2
General
Temperature
7.5°C / 45.5F to 32.5°C / 90.5F
Humidity
5% to 85% RH
Atmospheric Pressure
608 hPa to 1013 hPa (0.5 to 1 atm)
Power supply
220/240V
Power Consumption Maximum
1.5 kW or less
Standby
0.164 kWh (average; reference only)
Continuous
0.834 kWh (average; reference only)
Noise copying
71 dB or less
Noise Standby
50 dB or less
Ozone (avr of 8 hr)
0.05 ppm or less (avr; 0.10 ppm or less max.)
Copy paper
Keep wrapped, and protect against humidity.
Weight and Dimension
Product Dimension
24.0”W X 23.4”D X 23.0”H inch
Product Weight
181.5 lbs.
High-quality one-component toner ensures enhanced reproduction of text and photosTechnology (toner projection) ensures stable production of high-quality images3 Full line of basic featuresZooms between 49% and 204%, with nine (AB) / eight (Inch) preset reduction and enlargement reproduction ratiosAccommodates various paper sizes (A3/11”x 17” to postcard) and transfer media (tracing paper, transparency)Automatically recognizes the size of originals, selecting the best copy paper size (auto paper selection) or reproduction ratio (auto ratio selection)Capable of page separation, image composition, auto duplexing, frame erasing, and margin creationCompact duplexing unit designed with a set-back mechanismFront-loading-Paper is supplied from the front so that it requires less floor space.
