Technical Specification Voltage and Frequency 220Volt, 50Hz, 18V Standard Bolt M5-M14 High Tensile Bolt M5-M12 Coarse thread (length) 22 - 90 mm Max Fastening Torque 140 Nm Battery Type Lithium-ion Vibration: Fastening Bolt 11.5 m/sec² Vibration K factor 1.5 m/sec² Noise sound pressure 95 dB(A) Noise sound power 106 dB(A) Noise K factor 3 dB(A) Battery Quantity (5.0ah)2 Driving Shank 6.35mm ¼” Hex Blows per Minute (Hi) – ipm 0 - 4,100 ipm Blows per Minute (Lo) – ipm 0 - 2,000 ipm Machine Screw M4 – M8 Load Speed (Hi) 0 - 3,000 rpm Load Speed (Lo) 0 - 1,300 rpm Standard Accessories DC18RC COMPACT CHARGER Battery BL1850B 18v Li-ion MAKPAC CONNECTOR CASE (TYPE 2) Belt clip Weight and Dimension Unit Weight 3.30 lbs.
Technical Specification
Voltage and Frequency
220Volt, 50Hz, 18V
Standard Bolt
M5-M14
High Tensile Bolt
M5-M12
Coarse thread (length)
22 - 90 mm
Max Fastening Torque
140 Nm
Battery Type
Lithium-ion
Vibration: Fastening Bolt
11.5 m/sec²
Vibration K factor
1.5 m/sec²
Noise sound pressure
95 dB(A)
Noise sound power
106 dB(A)
Noise K factor
3 dB(A)
Battery Quantity
(5.0ah)2
Driving Shank
6.35mm ¼” Hex
Blows per Minute (Hi) – ipm
0 - 4,100 ipm
Blows per Minute (Lo) – ipm
0 - 2,000 ipm
Machine Screw
M4 – M8
Load Speed (Hi)
0 - 3,000 rpm
Load Speed (Lo)
0 - 1,300 rpm
Standard Accessories
DC18RC COMPACT CHARGER
Battery BL1850B 18v Li-ion
MAKPAC CONNECTOR CASE (TYPE 2)
Belt clip
Weight and Dimension
Unit Weight
3.30 lbs.
Ergonomically designed high comfort grip.Anti-bit-wobbling structureAssist mode for controlled screwdrivingBrushless MotorElectronic 2-speed impact power selectionAluminum hammer caseBelt clip
