Technical Specification Voltage 208-240Volt-60Hz Capacity 4.6 Cu.Ft Oven 1 Cleaning System Self-Clean Oven 1 Interior Lighting 1 Halogen (round) Electrical Specifications Amps @ 240 Volts 48.3 / 41.8 Connected Load (kW Rating) @ 240V 11.6 / 8.7 Minimum Circuit Required (Amps) 40A Power Supply Connection Location Left Rear Bottom Cooktop Bowl Type Chrome Cooking Surface Porcelain Knob Type Plastic Left Front 6" - 1125/1500 Watts Left Rear 8" - 1950/2600 Watts Right Front 8" - 1950/2600 Watts Right Rear 6" - 1125/1500 Watts Cooking Controls Bake Yes Cook Duration Yes Broil Variable Cancel Yes Clock Yes Automatic Oven (Delay Cook & Off) Multiple Functions Lockout Yes Up/Down Keypad Yes Self-Clean 2 3 Hours Timer Yes Oven Bake 6 pass 2750 Watts Broil 6 pass 3400 Watts Broil System High - Low Oven 1 Interior Color Slate Blue Oven 1 Interior Depth 18.75" Oven 1 Interior Height 17.50" Oven 1 Interior Width 24.12" Oven 1 Rack Configuration 2 Handle Oven 1 Rack Positions 5 positions Oven 1 Type Main Oven 1 Window Large Weight and dimension Unit Weight 145 Lbs. Unit Dimension 26.50"H x 30"W x 28.31"D inch
Technical Specification
Voltage
208-240Volt-60Hz
Capacity
4.6 Cu.Ft
Oven 1 Cleaning System
Self-Clean
Oven 1 Interior Lighting
1 Halogen (round)
Electrical Specifications
Amps
@ 240 Volts 48.3 / 41.8
Connected Load (kW Rating)
@ 240V 11.6 / 8.7
Minimum Circuit Required (Amps)
40A
Power Supply Connection Location
Left Rear Bottom
Cooktop
Bowl Type
Chrome
Cooking Surface
Porcelain
Knob Type
Plastic
Left Front
6" - 1125/1500 Watts
Left Rear
8" - 1950/2600 Watts
Right Front
Right Rear
Cooking Controls
Bake
Yes
Cook Duration
Broil
Variable
Cancel
Clock
Automatic Oven (Delay Cook & Off)
Multiple Functions
Lockout
Up/Down Keypad
2 3 Hours
Timer
Oven
6 pass 2750 Watts
6 pass 3400 Watts
Broil System
High - Low
Oven 1 Interior Color
Slate Blue
Oven 1 Interior Depth
18.75"
Oven 1 Interior Height
17.50"
Oven 1 Interior Width
24.12"
Oven 1 Rack Configuration
2 Handle
Oven 1 Rack Positions
5 positions
Oven 1 Type
Main
Oven 1 Window
Large
Weight and dimension
Unit Weight
145 Lbs.
Unit Dimension
26.50"H x 30"W x 28.31"D inch
Two 8” Elements 1950/2600 WattsQuick CleanPower CleanOven Rack HandlesDelay CleanHigh and low broil systemOven Door with Large WindowMultiple Broil OptionsADA ComplaintUL ApprovalBuilt with American PrideWhite color
