Technical Specification Power Supply 120Volt/60 Hz Capacity 5.0 Cu. Ft. Cooktop Specifications Cooking Surface Upswept / Sealed Burners Grate Color Black Matte Grate Material Cast Iron Grates Individual Knob Color Black Knob Type Plastic Black Left Front 9500 BTU Left Rear 9500 BTU Right Front 14000 BTU Right Rear 5000 BTU Cooking Controls Bake Yes Broil Broil Variable (400 - 500°F) Clear Button Yes Delay Clean Yes Start Time Yes Lockout Yes Lower Drawer Controls Storage Self-Clean 2 -3 Hours (Scroll thru) Timed Cook Option Yes Timed Shut-off 12 hours Timer Yes Timer Lockout Yes Drawer Drawer Functionality Storage Handle Integrated Oven Specifications Bake 18000 BTU Baking System Even Baking Technology Broil 13500 BTU Broiling System Vari-Broil™ High/Low Cleaning System Self-Clean Interior Color Slate Blue Interior Lighting 1 Incandescent Rack Configuration 2 Standard Rack Positions 6 positions Oven Window Extra-Large Visualite® Exterior Specifications Control Panel Finish Metal Cooktop Finish Porcelain Drawer Finish Integrated Handle Weight And Dimension Unit Weight 135 Lbs. UnitDimension 47.75"H x 29.87"W x 25.75"D
Technical Specification
Power Supply
120Volt/60 Hz
Capacity
5.0 Cu. Ft.
Cooktop Specifications
Cooking Surface
Upswept / Sealed Burners
Grate Color
Black Matte
Grate Material
Cast Iron
Grates
Individual
Knob Color
Black
Knob Type
Plastic Black
Left Front
9500 BTU
Left Rear
Right Front
14000 BTU
Right Rear
5000 BTU
Cooking Controls
Bake
Yes
Broil
Broil Variable (400 - 500°F)
Clear Button
Delay Clean
Start Time
Lockout
Lower Drawer Controls
Storage
Self-Clean
2 -3 Hours (Scroll thru)
Timed Cook Option
Timed Shut-off
12 hours
Timer
Timer Lockout
Drawer
Drawer Functionality
Handle
Integrated
Oven Specifications
18000 BTU
Baking System
Even Baking Technology
13500 BTU
Broiling System
Vari-Broil™ High/Low
Cleaning System
Interior Color
Slate Blue
Interior Lighting
1 Incandescent
Rack Configuration
2 Standard
Rack Positions
6 positions
Oven Window
Extra-Large Visualite®
Exterior Specifications
Control Panel Finish
Metal
Cooktop Finish
Porcelain
Drawer Finish
Integrated Handle
Weight And Dimension
Unit Weight
135 Lbs.
UnitDimension
47.75"H x 29.87"W x 25.75"D
Two 9500 BTU High Efficiency BurnersOne 5000 BTU Simmer BurnerOne-Touch Self CleanQuick BoilReady Select controlsElectronic Kitchen TimerStore-More™ Storage DrawerMatte Black Finish with Cast Iron GratesLow Simmer BurnerAuto Shut-OffOven Door with Large WindowTimed Cook OptionAttractive Stainless Steel ExteriorCSA CertificateBuilt with American PrideBlack Color
