General Specifications Power Supply 120Volt/60 Hz Capacity 5 Cu. Ft. Leveling Legs 4 Adjustable Power Type Gas Installation Type Free-Standing Cooktop Cooking Surface Porcelain Center 9500 BTU (Round) Left Rear 14000 BTU Right Rear 5000 BTU Left Front 9500 BTU Right Front 17000 BTU Electronic Ignition Yes Grate Color Black Matte Grate Material Cast Iron Grates 3 Continuous Grates Knob Color Stainless Steel Appearance Knob Type Plastic CC Certifications & Approvals Agency Approval CSA Blue Star / CSA Blue Flame Drawer Drawer Functionality Storage Drawer Handle Integrated Cooking Controls Bake Yes Broil Yes Cancel Button Yes Door Lock Yes Quick Bake Convection Yes Set Clock Yes Lockout Yes Self-Clean 2 3 Hours Start Button Yes Timer Function Yes Control Panel Finish Exterior Specifications Aluminum Panel Oven Bake 18000 BTU Broil 13500 BTU Baking System Even Baking Technology Broiling System Vari-Broil™ High/Low Cleaning System Self-Clean Convection System Quick Bake Hidden Bake Element Yes Oven 1 Interior Color Slate Blue Interior Lighting 1 Incandescent Rack Positions 6 positions Rack Configuration 2 Standard Type Main Window Extra-Large Visualite® Exterior Cooktop Finish Porcelain Drawer Finish Stainless Steel Smudge-Proof Exterior Finish Painted Weight And Dimension Unit Weight 205 Lbs. Unit Dimension 48.50"H x 29.87W x 29.25"D
General Specifications
Power Supply
120Volt/60 Hz
Capacity
5 Cu. Ft.
Leveling Legs
4 Adjustable
Power Type
Gas
Installation Type
Free-Standing
Cooktop
Cooking Surface
Porcelain
Center
9500 BTU (Round)
Left Rear
14000 BTU
Right Rear
5000 BTU
Left Front
9500 BTU
Right Front
17000 BTU
Electronic Ignition
Yes
Grate Color
Black Matte
Grate Material
Cast Iron
Grates
3 Continuous Grates
Knob Color
Stainless Steel Appearance
Knob Type
Plastic CC
Certifications & Approvals
Agency Approval
CSA Blue Star / CSA Blue Flame
Drawer
Drawer Functionality
Storage
Drawer Handle
Integrated
Cooking Controls
Bake
Broil
Cancel Button
Door Lock
Quick Bake Convection
Set Clock
Lockout
Self-Clean
2 3 Hours
Start Button
Timer Function
Control Panel Finish
Exterior Specifications
Aluminum Panel
Oven
18000 BTU
13500 BTU
Baking System
Even Baking Technology
Broiling System
Vari-Broil™ High/Low
Cleaning System
Convection System
Quick Bake
Hidden Bake Element
Oven 1 Interior Color
Slate Blue
Interior Lighting
1 Incandescent
Rack Positions
6 positions
Rack Configuration
2 Standard
Type
Main
Window
Extra-Large Visualite®
Exterior
Cooktop Finish
Drawer Finish
Stainless Steel Smudge-Proof
Exterior Finish
Painted
Weight And Dimension
Unit Weight
205 Lbs.
Unit Dimension
48.50"H x 29.87W x 29.25"D
9500 BTULeft Front14000 BTULeft Rear17000 BTURight Front5000 BTURight RearQuick Touch Self CleaningConvection OvenSmudge-Proof™ Stainless Steel2 StandardRack ConfigurationPower Burner offers more power and faster boil time Oven Door with Large WindowCSA CertifiedBuild with American PrideStainless Steel Color
