Technical Specification Voltage 120Volt/60 Hz Total Capacity 26.7Cu. Ft. Freezer Capacity 8.7 Cu. Ft. Fresh Food Capacity 18.48 Cu. Ft. Total Shelf Area 29 Sq. Ft. Fresh Food Shelf Area 229 Sq. Ft. Freezer Shelf Area 6.1 Sq. Ft. General Specifications Frost Free Yes Annual Energy (Kwh) 717 Condenser Type Dynamic Sound Package Quiet Pack Water Inlet Location Left Rear Bottom Installation Type Free-Standing Dispenser Dispenser Type Flush Single Paddle Crushed Ice Yes Cube Ice Yes Water Yes Dispenser Light Yes Display On/Off Yes Exterior Specifications Door Design Tall Door Style Soft-Arc Door Finish Stainless Steel Door Hinge Covers Hidden Cabinet Color Grey Toe Grille Grey Front Rollers Adjustable Rear Rollers Yes Door Gasket Grey Door Stops Yes Door Closers Yes Ice Maker Ice Maker Yes 2nd Ice Maker Optional Ice Maker On/Off Yes Ice Maker Location Fresh Food Section Electrical Specifications Amps 120 Volts: 8.5 Minimum Circuit Required (Amps) 15a Connected Load (Kw Rating) 120V: 1.02 Power Supply Connection Location Right Rear Bottom Controls Controls Express-Select Control Location Dispenser Control Buttons 11 Water Filter Change Indicator Light Yes Freezer Specifications Freezer Lighting Incandescent Drawer Yes Lower Basket Design Deep Plastic Basket With Adjustable Divider Lower Adjustable Basket Dividers White Upper Basket Design Full-Width Upper Basket Construction Powder-Coated Wire Fresh Food Energy Saver Plus Yes Lighting Design Incandescent Lighting Levels Dual-Level Water Filter Puresource Ultra Water Filter Location Top-Right Fresh Food Section Cantilever Shelves Yes Sliding Shelves 3 Half-Width 1 Quarter-Width Spillsafe Crispers 2 Smooth-Glide Humidity Controls 2 Meat / Deli Drawer Full-Width Full-Extension Cool Drawer 1-Gallon Adjustable Door Bins 2 Clear Dispenser Bin Clear Left Door Bottle Retainers 1 On Dispenser Bin Controls Style & Color Controls Capacitive Touch Weight And Dimension Unit Weight 352 Lbs. Unit Dimension 69.87"H X 36"W X 33.37"D
Technical Specification
Voltage
120Volt/60 Hz
Total Capacity
26.7Cu. Ft.
Freezer Capacity
8.7 Cu. Ft.
Fresh Food Capacity
18.48 Cu. Ft.
Total Shelf Area
29 Sq. Ft.
Fresh Food Shelf Area
229 Sq. Ft.
Freezer Shelf Area
6.1 Sq. Ft.
General Specifications
Frost Free
Yes
Annual Energy (Kwh)
717
Condenser Type
Dynamic
Sound Package
Quiet Pack
Water Inlet Location
Left Rear Bottom
Installation Type
Free-Standing
Dispenser
Dispenser Type
Flush Single Paddle
Crushed Ice
Cube Ice
Water
Dispenser Light
Display On/Off
Exterior Specifications
Door Design
Tall
Door Style
Soft-Arc
Door Finish
Stainless Steel
Door Hinge Covers
Hidden
Cabinet Color
Grey
Toe Grille
Front Rollers
Adjustable
Rear Rollers
Door Gasket
Door Stops
Door Closers
Ice Maker
Yes 2nd Ice Maker Optional
Ice Maker On/Off
Ice Maker Location
Fresh Food Section
Electrical Specifications
Amps
120 Volts: 8.5
Minimum Circuit Required (Amps)
15a
Connected Load (Kw Rating)
120V: 1.02
Power Supply Connection Location
Right Rear Bottom
Controls
Express-Select
Control Location
Control Buttons
11
Water Filter Change Indicator Light
Freezer Specifications
Freezer Lighting
Incandescent
Drawer
Lower Basket Design
Deep Plastic Basket With Adjustable Divider
Lower Adjustable Basket Dividers
White
Upper Basket Design
Full-Width
Upper Basket Construction
Powder-Coated Wire
Fresh Food
Energy Saver Plus
Lighting Design
Lighting Levels
Dual-Level
Water Filter
Puresource Ultra
Water Filter Location
Top-Right Fresh Food Section
Cantilever Shelves
Sliding Shelves
3 Half-Width 1 Quarter-Width Spillsafe
Crispers
2 Smooth-Glide
Humidity Controls
2
Meat / Deli Drawer
Full-Width Full-Extension Cool Drawer
1-Gallon Adjustable Door Bins
2 Clear
Dispenser Bin
Clear Left Door
Bottle Retainers
1 On Dispenser Bin
Controls Style & Color
Capacitive Touch
Weight And Dimension
Unit Weight
352 Lbs.
Unit Dimension
69.87"H X 36"W X 33.37"D
Puresource Ultra Ice & Water FiltrationSliding Spillsafe Glass ShelvesFull-Width Cool-Zone DrawerDual Ice ReadyEffortless Glide Freezer DrawersFreezer Basket With DividerEnergy Saver Plus TechnologyQuiet DesignENERGY STAR CertifiedCSA CertifiedSabbath Mode (Star-K® Certified)Ebony Color
