Technical Specifications Power Supply 120Volt/ 60Hz Total Capacity 18 Cu.Ft Freezer Capacity 3.98 Cu. Ft Fresh Food Capacity 14.1 Cu. Ft General Specifications Annual Energy 363KWH Condenser Type Dynamic Made In USA Yes Installation Type Free-Standing Ice Maker Ice Maker Optional Ice Maker Type IM-116 Certifications & Approvals ENERGY STAR® Certified Yes CSA Certified Yes ADA Compliant Yes Exterior Specifications Door Design Short Door Door Style UltraSoft™ Door Finish Stainless Steel Reversible Door Yes Handle Design Stainless Steel Door Hinge Covers Black Cabinet Finish Textured Cabinet Color Black Toe Grille Black Front Rollers Fixed Rear Rollers Yes Door Gasket Black Door Stops Yes Freezer Specifications Fixed Freezer Shelves 1 Full-Width Wire Fixed Door Racks 2 Full-Width White Controls Controls Electronic Control Location Top Center Electrical Specifications Amps @ 120 Volts 6 Minimum Circuit Required 15Amps Connected Load (kW Rating) @ 120V: 0.72 Power Supply Connection Location Right Rear Bottom Fresh Food Lighting Design Standard Sliding Shelves 2 Full-Width Glass Crispers 2 Clear Humidity Controls 2 Meat / Deli Drawer Half-Width Deli Gallon Door Storage 1 Fixed Door Racks 3 Full-Width – White Dairy Compartment Clear Dairy Door Weight and Dimension Product Weight 205 Dimension 65-3/8” H x 30” W x 30-1/8” D
Technical Specifications
Power Supply
120Volt/ 60Hz
Total Capacity
18 Cu.Ft
Freezer Capacity
3.98 Cu. Ft
Fresh Food Capacity
14.1 Cu. Ft
General Specifications
Annual Energy
363KWH
Condenser Type
Dynamic
Made In USA
Yes
Installation Type
Free-Standing
Ice Maker
Optional
Ice Maker Type
IM-116
Certifications & Approvals
ENERGY STAR® Certified
CSA Certified
ADA Compliant
Exterior Specifications
Door Design
Short Door
Door Style
UltraSoft™
Door Finish
Stainless Steel
Reversible Door
Handle Design
Door Hinge Covers
Black
Cabinet Finish
Textured
Cabinet Color
Toe Grille
Front Rollers
Fixed
Rear Rollers
Door Gasket
Door Stops
Freezer Specifications
Fixed Freezer Shelves
1 Full-Width Wire
Fixed Door Racks
2 Full-Width White
Controls
Electronic
Control Location
Top Center
Electrical Specifications
Amps @ 120 Volts
6
Minimum Circuit Required
15Amps
Connected Load
(kW Rating) @ 120V: 0.72
Power Supply Connection Location
Right Rear Bottom
Fresh Food
Lighting Design
Standard
Sliding Shelves
2 Full-Width Glass
Crispers
2 Clear
Humidity Controls
2
Meat / Deli Drawer
Half-Width Deli
Gallon Door Storage
1
3 Full-Width – White
Dairy Compartment
Clear Dairy Door
Weight and Dimension
Product Weight
205
Dimension
65-3/8” H x 30” W x 30-1/8” D
3 Full-Width- White Fixed Refrigerator Door Racks1 Full-Width Wire Fixed Freezer Shelves2 Full-Width White Fixed Freeze Door RacksFree-StandingOptional Ice maker ENERGY STAR® CertifiedCSA CertifiedADA CompliantStainless Steel color
