Technical Specifications Power Supply 120Volt/60 Hz Capacity 18 Cu.Ft. Freezer Capacity 3.98 Cu. Ft. Fresh Food Capacity 14.1 Cu. Ft. Total Shelf Area 20.5 Sq. Ft. Fresh Food Shelf Area 15.9 Sq. Ft Freezer Shelf Area 4.6 Sq. Ft. Annual Energy 404 kWH Condenser Type Dynamic Made In USA Yes Power Type Electric Installation Type Free-Standing Exterior Specifications Door Design Short Door Door Style UltraSoft Door Finish Textured Reversible Door Yes Handle Design Plastic Front Rollers Fixed Rear Rollers Yes Door Stops Yes Certifications & Approvals CSA Certified Yes ADA Compliant Yes Controls Controls Electronic Freezer Specifications Fixed Freezer Shelves 1 Full-Width Wire Fixed Door Racks 2 Full-Width White Electrical Specifications Amps @ 120 Volts 6 Minimum Circuit Required (Amps) 15A Connected Load (kW Rating) @ 120V 0.72 Power Supply Connection Location Right Rear Bottom Fresh Food Lighting Design Standard Lighting Levels Bright Lighting Sliding Shelves 2 Full-Width Wire Crispers 2 Clear Humidity Controls 2 Gallon Door Storage 1 Fixed Door Racks 3 Full-Width – White Dairy Compartment Clear Dairy Door Weight and Dimension Unit Weight 205 Lbs. Unit Dimension 66.62"H x 30”W x 30.12"D
Technical Specifications
Power Supply
120Volt/60 Hz
Capacity
18 Cu.Ft.
Freezer Capacity
3.98 Cu. Ft.
Fresh Food Capacity
14.1 Cu. Ft.
Total Shelf Area
20.5 Sq. Ft.
Fresh Food Shelf Area
15.9 Sq. Ft
Freezer Shelf Area
4.6 Sq. Ft.
Annual Energy
404 kWH
Condenser Type
Dynamic
Made In USA
Yes
Power Type
Electric
Installation Type
Free-Standing
Exterior Specifications
Door Design
Short Door
Door Style
UltraSoft
Door Finish
Textured
Reversible Door
Handle Design
Plastic
Front Rollers
Fixed
Rear Rollers
Door Stops
Certifications & Approvals
CSA Certified
ADA Compliant
Controls
Electronic
Freezer Specifications
Fixed Freezer Shelves
1 Full-Width Wire
Fixed Door Racks
2 Full-Width White
Electrical Specifications
Amps @ 120 Volts
6
Minimum Circuit Required (Amps)
15A
Connected Load (kW Rating) @ 120V
0.72
Power Supply Connection Location
Right Rear Bottom
Fresh Food
Lighting Design
Standard
Lighting Levels
Bright Lighting
Sliding Shelves
2 Full-Width Wire
Crispers
2 Clear
Humidity Controls
2
Gallon Door Storage
1
3 Full-Width – White
Dairy Compartment
Clear Dairy Door
Weight and Dimension
Unit Weight
205 Lbs.
Unit Dimension
66.62"H x 30”W x 30.12"D
Clear Dairy DoorReversible Door Independent Temperature ControlsStore-More Humidity ControlledCrisper DrawersStore-More Gallon Door ShelfFull-Width Wire Freezer RackADA?CompliantCSA CertifiedBuilt with American PrideBlack Color
