Technical SpecificationVoltage220-240VHertz50HZThrust4.4 lbf (19.6 N)Thrust Eff. Ratio12.1 lbf/kW (53.8 N/kW)Airflow9,200 cfm* (15,600 m3/h)Efficiency25.1 cfm/W (42.6 m3/h/W)Air Velocity @ 10 ft.600 fpm (3.0 m/s)7.0 mph (11.0 km/h)Sound Level @ 10 ft.62.5 dBAMotor SpecificationEnclosureTEAOHorsepower1/2 hp (0.375 kW)SpeedsSingleRotational Speed840 rpmCurrent3.1 APhase1 phService Factor1.0Ambient Temperature40°CInsulation ClassBThermally ProtectedYesShaft Size5/8 in. (15.9 mm)Blade SpecificationsDiameter36 in. (92 cm)Wings3Wing MaterialGalvanizedPitch22°Bore Size5/8 in. (1.59 cm)Weight and DimensionUnit Weight90 lb. (41 kg)Shipping Weight92 lb. (42 kg)Unit Dimension39.75”H x 40.75”W x 19.75”D (1010x1035x502 mm)
Technical Specification
Voltage
220-240V
Hertz
50HZ
Thrust
4.4 lbf (19.6 N)
Thrust Eff. Ratio
12.1 lbf/kW (53.8 N/kW)
Airflow
9,200 cfm* (15,600 m3/h)
Efficiency
25.1 cfm/W (42.6 m3/h/W)
Air Velocity @ 10 ft.
600 fpm (3.0 m/s)
7.0 mph (11.0 km/h)
Sound Level @ 10 ft.
62.5 dBA
Motor Specification
Enclosure
TEAO
Horsepower
1/2 hp (0.375 kW)
Speeds
Single
Rotational Speed
840 rpm
Current
3.1 A
Phase
1 ph
Service Factor
1.0
Ambient Temperature
40°C
Insulation Class
B
Thermally Protected
Yes
Shaft Size
5/8 in. (15.9 mm)
Blade Specifications
Diameter
36 in. (92 cm)
Wings
3
Wing Material
Galvanized
Pitch
22°
Bore Size
5/8 in. (1.59 cm)
Weight and Dimension
Unit Weight
90 lb. (41 kg)
Shipping Weight
92 lb. (42 kg)
Unit Dimension
39.75”H x 40.75”W x 19.75”D (1010x1035x502 mm)
Narrow fan profile with ergonomic pull handle and integrated base assembly handlesHeavy-duty galvanized steel base assemblyCorrosion resistance inside and outRubber wheels designed in-line with housingStacking tabs includedLow sound levels exceeding OSHA regulationsStacking capability up to four fans highMade in USA with dependable, long lasting componentsHigh density polyethylene housing for superior impact, extreme temperature and abrasion resistance
