Technical specification Power supply voltage 1Phase, 220-240V 50HZ Climate class SN/N/ST/T Electrical protection class I Ice making rating (amps) 1.8 amp Ice harvest rating (amps) 2.6 amp Ice making capacity (kg/24h) 45kg/24hour Refrigerant charge R134a, 245g Vesicant C5h10 Unit dimensions 31”H x 18”W x 16”D Net weight/gross weight(kg) 28.3kg (62Lb) Connection Power cord 0.75 mm2 Water supply 6.35mm diameter Drain F16 sylphon bellowss(rear) Water consumption(l/24h) 50l Max ice storage capacity(kg) 15kg Accessories Shovel, installation kits Running conditions Room temp 10-38 Water supply temp 5-35 Water supply pressure 0.04-0.6 Mpa
Technical specification
Power supply voltage
1Phase, 220-240V 50HZ
Climate class
SN/N/ST/T
Electrical protection class
I
Ice making rating (amps)
1.8 amp
Ice harvest rating (amps)
2.6 amp
Ice making capacity (kg/24h)
45kg/24hour
Refrigerant charge
R134a, 245g
Vesicant
C5h10
Unit dimensions
31”H x 18”W x 16”D
Net weight/gross weight(kg)
28.3kg (62Lb)
Connection
Power cord
0.75 mm2
Water supply
6.35mm diameter
Drain
F16 sylphon bellowss(rear)
Water consumption(l/24h)
50l
Max ice storage capacity(kg)
15kg
Accessories
Shovel, installation kits
Running conditions
Room temp
10-38
Water supply temp
5-35
Water supply pressure
0.04-0.6 Mpa
2.6 Amp Ice Making Rating
