Model 31A Volt 230V / 50HZ Motor: power input (230V) 1950 W / S6 40% Motor: power output (230V) 1100 W / S1 100% Max. width / Sanding diameter 150 mm / Ø 300 mm Max. sanding depth 170mm / 150 mm Table size 190 x 330 / 230 x 440 mm Mitre capacity 0 – -45° / + 15° – -45° Sanding disc diameter 300 mm Disc speed 1400 rpm Abrasive belt 150 x 1220 mm Tilting sanding belt 0 – 90° Belt speed 12 m/sec. Table tilt - 45° - 0°-+15° Tilting supplementary table - 45° - 0° Dimensions (LxWxH) 1400 x 530 x 705 mm Dust port 100 mm Weight 124 kg
Model
31A
Volt
230V / 50HZ
Motor: power input (230V)
1950 W / S6 40%
Motor: power output (230V)
1100 W / S1 100%
Max. width / Sanding diameter
150 mm / Ø 300 mm
Max. sanding depth
170mm / 150 mm
Table size
190 x 330 / 230 x 440 mm
Mitre capacity
0 – -45° / + 15° – -45°
Sanding disc diameter
300 mm
Disc speed
1400 rpm
Abrasive belt
150 x 1220 mm
Tilting sanding belt
0 – 90°
Belt speed
12 m/sec.
Table tilt
- 45° - 0°-+15°
Tilting supplementary table
- 45° - 0°
Dimensions (LxWxH)
1400 x 530 x 705 mm
Dust port
100 mm
Weight
124 kg
Convenient knob for easy adjustment of the belt tensionMitre gauge for more precisionPre-set stops at 90° and 45°
