Technical Specification
Voltage
110-240
Hertz
50/60
Display
Screen Size (Diagonal)
60" (152.4cm)
Aspect Ratio
16:9
Pixel Resolution
1920 x 1080
Viewing Angle
89° (Right / Left), 89° (Up / Down)
LCD Sync Rate
XR 400/480
TV Scan Lines
Up to 1080
TV Tuner
DVB-T2
Speaker
Sound
Speaker Type: Bass reflex speaker
Sound Mode: Standard, cinema, sports, music, game, compressed audio
Stereo System: NICAM/A2
Dolby Digital
Dolby Digital, Dolby Digital Plus, Dolby Pulse
Power Consumption
Normal:165 W
Standby: 0.3 W
Power
10 W + 10 W = 20 W
Orientation
Speaker Configuration: 2-channel, full range 1.2 x 3.1" (30 x 80 mm) x 2
Inputs/Outputs
4 x HDMI (1 side / 3 bottom)
1 x Analog audio input for HDMI (Rear)
2 x USB 2.0 (Side)
1 x Ethernet connection (Rear)
2 x Composite video inputs (1 Rear / 1 rear hybrid with component)
1 x Component video (Y/Pb/Pr) input (Rear / Hybrid)
1 x RF connection input (Bottom)
2 x Analog audio inputs (Rear)
1 x Digital audio output (Rear)
1 x Audio out (Side / Hybrid with HP)
1 x Headphone out (Side / Hybrid with audio out)
Convenience
Remote Control
Yes
Unit Weight
With Stand: 45.2 lb (20.5 kg)
Without Stand: 43.9 lb (19.9 kg)
Unit Dimensions
With Stand: 33.3”H x 53.9”W x 9.1"D (846x1370x230mm)
Without Stand: 31.9”H x 53.9”W x 3.3"D (811x1370x84 (48)mm)
