UPS type Line Interactive UPS protects connected equipment from blackouts, brownouts, overvoltages, surges and line noise. Includes LAN port, bundled software and modem line surge suppression. Input/output voltage 230 Input/output frequency (Hz) 50/60 Ouput VA 300 Output watts 180 On-line waveform Pure Sine On battery waveform PWM Sinusoidal Voltage regulation Accepts and regulates any input voltage between 159 and 282 back to usable 230v levels, without consuming battery power. Full load runtime (min.) 5 1/2 load runtime (min.) 17 Typical runtime (PC w/15" mon.) up to 15 min. External battery compatible Not supported. See selected Smart XL, RM and Data center models for this capability. Recharge rate to 90% (hours) 4-Feb Transfer time (milliseconds.) 4-Feb Suppression joule rating 160 Maximum surge current (amps) 27,000 Suppression response time Less than 1 nanosecond EMI/RFI noise reduction > 40 dB @ 1 MHz High volt switch to battery 282 Low volt switch to battery 159 UPS supported outlet type / qty. 2 IEC-320 Receptacles Cord length 6.56 ft. / 2.00 m Plug type (m) IEC-320 Male Dimensions HxWxD (in) 8.3”H x 5.1”W x 7.1“D Shipping weight 8 lbs. / 4 kg Fax/modem surge protection Set of RJ11 jacks protects a single phone line Network interface port Built in DB9 standard communications port for use with PowerAlert software and cabling. Software & cable included Includes cable and PowerAlert software. Battery access User accessible Door Controls, indicators and additional features On/off and Self test/alarm silence switches, LEDs indicate on-line,on-battery, voltage correction, and battery low/replace, load level. Audible alarms.
UPS type
Line Interactive UPS protects connected equipment from blackouts, brownouts, overvoltages, surges and line noise. Includes LAN port, bundled software and modem line surge suppression.
Input/output voltage
230
Input/output frequency (Hz)
50/60
Ouput VA
300
Output watts
180
On-line waveform
Pure Sine
On battery waveform
PWM Sinusoidal
Voltage regulation
Accepts and regulates any input voltage between 159 and 282 back to usable 230v levels, without consuming battery power.
Full load runtime (min.)
5
1/2 load runtime (min.)
17
Typical runtime (PC w/15" mon.)
up to 15 min.
External battery compatible
Not supported. See selected Smart XL, RM and Data center models for this capability.
Recharge rate to 90% (hours)
4-Feb
Transfer time (milliseconds.)
Suppression joule rating
160
Maximum surge current (amps)
27,000
Suppression response time
Less than 1 nanosecond
EMI/RFI noise reduction
> 40 dB @ 1 MHz
High volt switch to battery
282
Low volt switch to battery
159
UPS supported outlet type / qty.
2 IEC-320 Receptacles
Cord length
6.56 ft. / 2.00 m
Plug type (m)
IEC-320 Male
Dimensions HxWxD (in)
8.3”H x 5.1”W x 7.1“D
Shipping weight
8 lbs. / 4 kg
Fax/modem surge protection
Set of RJ11 jacks protects a single phone line
Network interface port
Built in DB9 standard communications port for use with PowerAlert software and cabling.
Software & cable included
Includes cable and PowerAlert software.
Battery access
User accessible Door
Controls, indicators and additional features
On/off and Self test/alarm silence switches, LEDs indicate on-line,on-battery, voltage correction, and battery low/replace, load level. Audible alarms.
2 outlets provide battery backup and surge protection Automatic Voltage Regulation (AVR) corrects brownouts and over voltages without draining battery power Built-in RJ11 jacks provide complete modem/fax surge protection Serial port and free software facilitate unattended shutdown.
