Technical Specification Voltage 120V Hertz 50HZ Timer Type Mechanical Lid Instruction Yes Agitator Extra Roll plus Agitator-white Basket Finish Spreckle Basket Volume 3.0 + /- . 1 Cubic Feet Filter Self Cleaning Dispenser 2 : Agitator Mtd Fabric Softener direct in Bleach Motor ½ HP, 2 speed (50Hz) Agitation (approx) HI – 180 Strokes / Min, LO – 120 Strokes / Min Spin (approx) HI – 640 RPM, LO – 423 RPM Timer 7 Cycles Water Temp. Switch Rotary, 3 – Position (HC, WC, CC) End of Cycle Signal Yes Extra Rinse Option No Speed Select Switch No Other Features Flapper pump, FM – Front Mastic Pad Inlet Hose Domestic / Standard Inlet Valve 45 / 55 Electrical Requirement 120 Volt, 50 Hz, 10 Amps Power Cord 3 – Prong Domestic Plug Codes UL Approved Unit Dimension: 42.5”H x 27.0”W x 25.5”D
Technical Specification
Voltage
120V
Hertz
50HZ
Timer Type
Mechanical
Lid Instruction
Yes
Agitator
Extra Roll plus Agitator-white
Basket Finish
Spreckle
Basket Volume
3.0 + /- . 1 Cubic Feet
Filter
Self Cleaning
Dispenser
2 : Agitator Mtd Fabric Softener direct in Bleach
Motor
½ HP, 2 speed (50Hz)
Agitation (approx)
HI – 180 Strokes / Min, LO – 120 Strokes / Min
Spin (approx)
HI – 640 RPM, LO – 423 RPM
Timer
7 Cycles
Water Temp. Switch
Rotary, 3 – Position (HC, WC, CC)
End of Cycle Signal
Extra Rinse Option
No
Speed Select Switch
Other Features
Flapper pump, FM – Front Mastic Pad
Inlet Hose
Domestic / Standard
Inlet Valve
45 / 55
Electrical Requirement
120 Volt, 50 Hz, 10 Amps
Power Cord
3 – Prong Domestic Plug
Codes
UL Approved
Unit Dimension:
42.5”H x 27.0”W x 25.5”D
Extra Roll Action Plus Agitator3 Temperatures3 Water LevelsHand Washable CyclePorcelain BasketBleach and Fabric Softener DispensersON/OFF End-Of-Cycle Signal Spill Guard Top Self-Cleaning Lint Filter 120/50 VoltsDomestic Plug.
