Technical Specification Power Supply 120V 60HZ Cylinder volume 7.0 CU.FT (198 liter) Capacity 18 lb. (8.2 kg ) Control option push-to-start Color white Motor (capacitor start and thermal protected) .33 HP Type of gas factory equipped natural/mixed gas Air outlet diameter 4”(102 mm) Exhaust airflow 220 cfm (105liters/sec) Cycle temperature normal, perm press delicate, no heat Agency approvals ccsaus Heating element 25,000 btu Weight And Dimensions Unit weight 150 lbs. (68 kg ) Shipping weight 161 lb. (73 kg ) Unit Dimensions 43”H X 26.875”W X 28”D (1092H X 683W X 711D mm ) Shipping dimensions 45”H X 30.5”W X 29.5”D (1143 X 775 X 762 mm )
Technical Specification
Power Supply
120V 60HZ
Cylinder volume
7.0 CU.FT (198 liter)
Capacity
18 lb. (8.2 kg )
Control option
push-to-start
Color
white
Motor (capacitor start and thermal protected)
.33 HP
Type of gas
factory equipped natural/mixed gas
Air outlet diameter
4”(102 mm)
Exhaust airflow
220 cfm (105liters/sec)
Cycle temperature
normal, perm press delicate, no heat
Agency approvals
ccsaus
Heating element
25,000 btu
Weight And Dimensions
Unit weight
150 lbs. (68 kg )
Shipping weight
161 lb. (73 kg )
Unit Dimensions
43”H X 26.875”W X 28”D (1092H X 683W X 711D mm )
Shipping dimensions
45”H X 30.5”W X 29.5”D (1143 X 775 X 762 mm )
.33 HPMotorIndustry’s largest door opening 2.06 sq. ft. (1914 cm²)ccsausAgency approvals Push-to-startControl optionQuiet, efficient blower systemNormal, Perm press delicate, No heatCycle temperatureDoor is reversible for installation flexibilityHigh efficiency exhaust blower with superior airflow 220 cfm (105 liters/sec)Exhaust airflow100% serviceable from the frontSpace-saving narrow cabinet Upfront lint filter easy to clean and securedDurable galvanized steel cylinder
