Technical Specification Voltage and Frequency 220V 50HZ Chilling Capacity (LPH) 30.0 LPH Chilling Capacity (GPH) 8 LPH F.L. Amps 2.0A Rated Watts 370 W Glass Filler Yes Foot Pedal Yes Color Light Gray Granite Bubbler Style Flexi-Guard Safety Bubbler Mounting Floor Mount/Freestanding Refrigerant Type R134a Drinking water Temperature 50°F Inlet water Temperature 80°F Compliance ASME A112.19.3/CSA B45.4 Yes Buy American Act Yes CAN/CSA C22.2 No. 120 Yes NSF 372 (lead free) Yes NSF 61 Yes UL 399 Yes Global Compliance CE Yes Weight And Dimension Product Dimensions 41.49"H x 14.48"W x 17.99"L Product Shipping Dimensions 46.49"H x 16.81"W x 20.31"L Product Shipping Wight 77.16 lbs.
Technical Specification
Voltage and Frequency
220V 50HZ
Chilling Capacity (LPH)
30.0 LPH
Chilling Capacity (GPH)
8 LPH
F.L. Amps
2.0A
Rated Watts
370 W
Glass Filler
Yes
Foot Pedal
Color
Light Gray Granite
Bubbler Style
Flexi-Guard Safety Bubbler
Mounting
Floor Mount/Freestanding
Refrigerant Type
R134a
Drinking water Temperature
50°F
Inlet water Temperature
80°F
Compliance
ASME A112.19.3/CSA B45.4
Buy American Act
CAN/CSA C22.2 No. 120
NSF 372 (lead free)
NSF 61
UL 399
Global Compliance
CE
Weight And Dimension
Product Dimensions
41.49"H x 14.48"W x 17.99"L
Product Shipping Dimensions
46.49"H x 16.81"W x 20.31"L
Product Shipping Wight
77.16 lbs.
Glass Filler PreppedGENERALSelf-contained, electric refrigerated, floor model water cooler. Capacity of 50°F drinking water, based upon 80°F inlet water. Non-pressurized tank system is standard. Non-pressurized water tank is located after bubbler valve, so that tank is subject to line pressure only when valve button is pressed. Unit shall be lead-free design which is certified to NSF/ANSI 61 and 372 and meets Federal and State low-lead requirements.STANDARD FEATURESRemovable front panel offers easy accessibility to interiorExtra deep basin minimizes splashing; with integral Vandal-resistant strainerExclusive Flexi-Guard® Safety bubblerCooler Panel Finish options: Impact-resistant vinyl coating or stainless steelRated for Indoor useCOOLING SYSTEMCompressor: Hermetically sealed, reciprocating type, single phase. Sealed-in lifetime lubrication.Condenser: Fan cooled copper tube with aluminum fins.Cooling Unit: Combination tube-tank type. Tube portion is continuous coil of copper tubing. Fully insulated with EPS foam which meets Underwriters Laboratories Inc. Requirements for self-extinguishing material.Refrigerant Control: Refrigerant R134a is controlled by accurately calibrated capillary tube.Temperature Control: Easily accessible enclosed adjustable thermostat is factory preset. Requires no adjustment other than for altitude requirements.CONSTRUCTIONStainless Steel basin with integral Vandal-resistant strainerGalvanized structural steel cooler chassis provides structural integrityCooler cabinet available as Light Gray Granite or Sandalwood Vinyl Clad Steel or Stainless Steel (additional cost) constructionExclusive Flexi-Guard® Safety Bubbler utilizes an infused anti-microbial pliable polyester elastomer to prevent accidental mouth injuries. Flexes on impact.Cabinet design allows for flush to wall mounting or free standing
