Technical Specification Voltage 220-240V Frequency 50/60HZ Power 9000 W Amperage 37.5 A Wire Size 8 AWG Minimum/Maximum GPM 0.25 - 2.50 GPM Unit Height 7.8” Unit Width 3.5” Unit Depth 6.1” Unit Weight 5 Lb. WATER TEMPERATURE INCREASE CHART WATER FLOW (GPM) TEMPERATURE 0.75 85 1.00 61 2.00 30 3.00 20 INCOMMING WATER TEMPERATURE ( °F) UNITS TO INSTALL 65-80 1 35-64 2 Less than 34 3
Technical Specification
Voltage
220-240V
Frequency
50/60HZ
Power
9000 W
Amperage
37.5 A
Wire Size
8 AWG
Minimum/Maximum GPM
0.25 - 2.50 GPM
Unit Height
7.8”
Unit Width
3.5”
Unit Depth
6.1”
Unit Weight
5 Lb.
WATER TEMPERATURE INCREASE
CHART
WATER FLOW (GPM)
TEMPERATURE
0.75
85
1.00
61
2.00
30
3.00
20
INCOMMING WATER TEMPERATURE ( °F)
UNITS TO INSTALL
65-80
1
35-64
2
Less than 34
3
Expandable for larger applications by installing multiple units in parallelSophisticated safety featuresPerfect for your home, business, Remote areas!
