Technical Specification Voltage 120V 60HZ Power Consumption 1.5kW Power Consumption (Sleep Mode) 0.8W Amps 7.5A Standard Paper Capacity One 550 Sheet Paper Cassette 100-sheet Stack Bypass Maximum Paper Capacity 2,270 Sheets Output Paper Capacity (20 lb. Bond): Standard: 250 Sheets (Inner Tray) Maximum: 3,000 Sheets (w/Staple Finisher or Booklet Finisher) Features Type Color Digital Multifunction Imaging System Letter: Up to 25/25 ppm Legal/11 x 17: Up to 15 ppm Functions Standard: Copy, Print (UFR II), Scan, Send Optional: Print (PCL, Adobe® PostScript® 3?), Fax (Up to 2 Lines) Operation Panel 7 WVGA Full-Color TFT Screen Image Server Memory Standard: 2GB RAM Maximum: 2GB RAM Hard Disk Drive Standard: 80GB Maximum: 80GB Network Interface Connection Standard: 1000Base-T/100Base-TX/10Base-T Optional: Wireless LAN (IEEE 803.1x via third-party adapter) Other Interface Standard: USB 2.0 (Host) x 2, USB 2.0 (Device) Optional: Device Port [USB 2.0 (Host) x 2], Copy Control Interface Memory Media Standard USB Memory Optional SD, SDHC, CompactFlash, Memory Stick, Microdrive Scan Specifications Network TWAIN Scan Standard Network Scan Utility Color Network ScanGear Multiple Copies 1 to 999 Optional Dual 550 Sheet Paper Cassettes Output Sizes Cassette Cassette 1: 11 x 17, Letter, Executive Cassettes 2/3/4: 12 x 18,* 11 x 17, Legal, Letter, Letter-R, Statement-R, Executive, Custom Size (5-1/2 x 7-1/8 to 12 x 15-1/8) Bypass 12 x 18, 12-5/8 x 17-11/16, 11 x 17, Legal, Letter, Letter-R, Statement, Statement-R, Executive, Custom Size (3-7/8 x 5-1/2 to 12-5/8 x 18) Weight and Dimension Product Dimension 36.53"W X 22.24"D X 26.77"H inch Product Weight 198 lbs.
Technical Specification
Voltage
120V 60HZ
Power Consumption
1.5kW
Power Consumption (Sleep Mode)
0.8W
Amps
7.5A
Standard Paper Capacity
One 550 Sheet Paper Cassette
100-sheet Stack Bypass
Maximum Paper Capacity
2,270 Sheets
Output Paper Capacity
(20 lb. Bond): Standard: 250 Sheets (Inner Tray)
Maximum: 3,000 Sheets (w/Staple Finisher or Booklet Finisher)
Features
Type
Color Digital Multifunction Imaging System
Letter: Up to 25/25 ppm
Legal/11 x 17: Up to 15 ppm
Functions
Standard: Copy, Print (UFR II), Scan, Send
Optional: Print (PCL, Adobe® PostScript® 3?), Fax (Up to 2 Lines)
Operation Panel
7 WVGA Full-Color TFT Screen
Image Server Memory
Standard: 2GB RAM
Maximum: 2GB RAM
Hard Disk Drive
Standard: 80GB
Maximum: 80GB
Network Interface Connection
Standard: 1000Base-T/100Base-TX/10Base-T
Optional: Wireless LAN (IEEE 803.1x via third-party adapter)
Other Interface
Standard: USB 2.0 (Host) x 2, USB 2.0 (Device)
Optional: Device Port [USB 2.0 (Host) x 2], Copy Control Interface
Memory Media Standard
USB Memory
Optional
SD, SDHC, CompactFlash, Memory Stick, Microdrive
Scan Specifications Network TWAIN Scan
Standard
Network Scan Utility
Color Network ScanGear
Multiple Copies
1 to 999
Dual 550 Sheet Paper Cassettes
Output Sizes
Cassette
Cassette 1: 11 x 17, Letter, Executive
Cassettes 2/3/4: 12 x 18,* 11 x 17, Legal, Letter, Letter-R, Statement-R, Executive, Custom Size (5-1/2 x 7-1/8 to 12 x 15-1/8)
Bypass
12 x 18, 12-5/8 x 17-11/16, 11 x 17, Legal, Letter, Letter-R, Statement, Statement-R, Executive, Custom Size (3-7/8 x 5-1/2 to 12-5/8 x 18)
Weight and Dimension
Product Dimension
36.53"W X 22.24"D X 26.77"H inch
Product Weight
198 lbs.
Intuitive 17.8 cm TFT LCD touch screen with tilt-functionEasy control of access and usage per userFlexible media and finishing supportWith Standard UFR II printing, one 520-Sheet Cassette,one 550 Sheet Cassette, 100-Sheet Stack Bypass, 2GB of RAM, 80GB HDD, 10/100/1000 Base-TX Ethernet,and USB 2.0 connectivity, Color Universal Send with PDF High Compression, HDD Data Erase, IP Sec, Color Network ScanGear and Drum Units Including: 1.DADF-AJ1(INCH/AB)1.CABINET TYPE-D1.SuperG3 FAX Board-AH2Stunning in-house document publishingLow energy consumption2270 sheets (80 gsm) Maximum paper input capacityENERGY STAR® qualified deviceApprox. 34 sec from power ON (Normal mode),10 sec from power ON (Quick Start mode) Warm UP
