Technical Specification Electrical Specifications 220V 50HZ Cylinder Volume - cu. ft. (liters) 7.0 (198) Cycle Time - minutes Timed & Auto Cycles Motor HP 1/3 HP, Cycle/Temperature Regular/Perm Press Delicate Motor - RPM 50 Hz: 1425 Heating Element 3100 W, 230 V Air Outlet Diameter - in (mm) 4" (102) Exhaust Airflow*** - cfm (cu. meter) 220 (374 M3 /hr) Agency Approval CE Activation Push-to-Start Top and Lid Finish Powder Paint Color White Dimensions & Weight Width - in (mm) 26 7/8" (683) Depth - in (mm) 28" (711) Height* - in (mm) 43" (1092) Work Surface Height - in (mm) 36" (914) Weight - lb (kg) 130 (59) Shipping Weight -lb (kg) 140 (64)
Technical Specification
Electrical Specifications
220V 50HZ
Cylinder Volume - cu. ft. (liters)
7.0 (198)
Cycle Time - minutes
Timed & Auto Cycles
Motor HP
1/3 HP,
Cycle/Temperature
Regular/Perm Press Delicate
Motor - RPM
50 Hz: 1425
Heating Element
3100 W, 230 V
Air Outlet Diameter - in (mm)
4" (102)
Exhaust Airflow*** - cfm (cu. meter)
220 (374 M3 /hr)
Agency Approval
CE
Activation
Push-to-Start
Top and Lid Finish
Powder Paint
Color
White
Dimensions & Weight
Width - in (mm)
26 7/8" (683)
Depth - in (mm)
28" (711)
Height* - in (mm)
43" (1092)
Work Surface Height - in (mm)
36" (914)
Weight - lb (kg)
130 (59)
Shipping Weight -lb (kg)
140 (64)
Electronic ControlPush-to-Start Activation1425 RPM Motor1/3 HP Motor 3100W Low Heating ElementPowder Paint Top and Lid FinishHeight adjustable feetDoor opening on the sideDanger fire hazardDryer ling trap Freestanding White ColorCE Approved.
