Technical Specification Electrical Specifications 220V 50HZ Cylinder Volume - cu. ft. (liters) 7.0 (198) Cycle Time - minutes Timed & Auto Cycles Motor HP 1/3 HP, Cycle/Temperature Regular/Perm Press Delicate Motor - RPM 50 Hz: 1425 Heating Element 4800 W, 230 V Air Outlet Diameter - in (mm) 4" (102) Exhaust Airflow*** - cfm (cu. meter) 220 (374 M3 /hr) Agency Approval CE Activation Push-to-Start Top and Lid Finish Powder Paint Color White Dimensions & Weight Unit Dimension 43”H x 26.87”W x 28”D Unit Weight 130 Lbs./ 59 Kg Shipping Weight 140 Lbs./ 64 Kg
Technical Specification
Electrical Specifications
220V 50HZ
Cylinder Volume - cu. ft. (liters)
7.0 (198)
Cycle Time - minutes
Timed & Auto Cycles
Motor HP
1/3 HP,
Cycle/Temperature
Regular/Perm Press Delicate
Motor - RPM
50 Hz: 1425
Heating Element
4800 W, 230 V
Air Outlet Diameter - in (mm)
4" (102)
Exhaust Airflow*** - cfm (cu. meter)
220 (374 M3 /hr)
Agency Approval
CE
Activation
Push-to-Start
Top and Lid Finish
Powder Paint
Color
White
Dimensions & Weight
Unit Dimension
43”H x 26.87”W x 28”D
Unit Weight
130 Lbs./ 59 Kg
Shipping Weight
140 Lbs./ 64 Kg
Rotary KnobPush-to-Start Activation1425 RPM Motor1/3 HP Motor 4800W Heating ElementPowder Paint Top and Lid FinishHeight adjustable feetDoor opening on the sideDanger fire hazardDryer ling trap FreestandingCE Approved.
